{TARGET} (Large Display)
The coordinate values in the current work coordinate system, of the end
point of commanded axis moves in normal size characters.
Figure 8.8
Results after Pressing {TARGET} Softkey
PRGRAM A B S TARGET D T G AXIS
SELECT
E-STOP
TARGET [ MM ] (ACTIVE PROGRAM NAME)
X - 7483 . 647
Z - 7483 . 647
U - 7483 . 647
F 0.000 MMPM S 00
{TARGET} (Small Display)
The coordinate values of the end point of the currently executing axis
move is displayed at a position in the current work coordinate system for
all system axes in the active process (only available when more than 9 axis
are AMPed in the system, or more than 8 axis in the process for dual
process systems).
