Displays and Graphics
Chapter 8
8-36
3. To change the size of the window, use the {INCR WINDOW} or
{DECR WINDOW} softkeys. To change the window size at a faster rate,
press and hold the [SHIFT] key while pressing the {INCR WINDOW} or
{DECR WINDOW} softkeys.
Each timeyou press: The Zoom Window:
{INCR WINDOW} increases in size.
{DECR WINDOW} decreases in size.
4. Once the size and the location of the window are correct, press the
{ZOOM} softkey to return to the regular QuickCheck graphics screen.
(softkey level 4)
INCR
WINDOW
DECR
WINDOW
ZOOM
ABORT
ZOOM
The graphics screen is automatically cleared of the previously plotted tool
paths. The control begins plotting new tool paths from its current location
in the program using the new window size.
If you press {ZOOM BACK}: It:
one, two or three times
reverses thezoom in increments, going backto your
most recent zoom (not theoriginal).
a fourth time returns the graphicsscreen to the default size.
When you press the {ZOOM BACK} softkey, the control clears the graphics
screen of any previously plotted tool paths. The control resumes plotting
new tool paths from its current location in the program using the current
window size.
