Manual

Communications
Chapter 9
9-4
All of the following parameters can be set independently for each
communication port (A or B).
DEVICE (setting type of peripheral)
Select your peripheral device immediately after selecting your serial port.
The devices with default communication parameters stored in the control
are listed in Table 9.A. If the device that you are using is not listed, select
either USER PUNCH, USER PRINTER, or USER READER.
Important: You cannot select the same device for both peripheral ports.
Once you select a device for PORT A, that device is no longer an option
available for PORT B and vice-versa.
Table 9.A
Available Devices For Communication
Device Device Type
Allen-Bradley 1770-SB Cartridge
Ricoh PTR240R
Facit N4000 Reader
Decitek AB 8000-XPDR
DSI SP75
Facit 4070 Punch
Facit N4000
Epson LX-810 (USA) Printer
Epson SP-500 (JAPAN)
User Punch
User Reader User Defined
User Printer
Teach Pendant
PAL-RS232 Comm
ODS ODS Terminal
Generic Level_2 Computer using onlylevel 2protocol
Greco Minifile Intelligent Storage
Intelligent Device PersonalComputer using
Communication Software
For more information on some of these peripheral devices and their
function, refer to your 9/Series CNC Integration and Maintenance
Manual.
