Words in a part program consist of addresses and numeric values.
Component: Description:
Address A character to designatethe assignedword function.
Numeric value A numeralto expressthe event called out bythe word.
Figure 10.4
Word Configuration
Word Word
G 0 1
X
1 .3 1
Address Numeric
value
For each word used in a part program, there is a format that designates the
number of digits allowable as a numeric value for that word. The format
for an M-code or word, for example, is normally M2 which indicates that
an M address can be followed by only two digits.
For words that allow the use of a decimal point in a numeric value, the
decimal point format is used. In this case, the numeral to the left of the
decimal point indicates the number of digits acceptable as integers, and the
numeral to the right of the decimal point indicates the number of fractional
digits acceptable.
The format “X3.4” for an X-word, indicates that three digits to the left and
four digits to the right of the decimal are acceptable as numeric values.
With this format selected, the maximum programmable value for an
X-word would be 999.9999.
The system installer can choose from these programming format types in
AMP:
Leading Zero Suppression ---- enable or disable
Trailing Zero Suppression ---- enable or disable
10.4
Word Formats and
Functions
10.4.1
Leading Zero and Trailing
Zero Suppression
