Table 10.E
G-code Table
A B C Modal Function Type
G00 01 Rapid Positioning Modal
G01 LinearInterpolation
G02 CircularInterpolation (Clockwise)
G03 CircularInterpolation (Counterclockwise)
G04 00 Dwell Non-Modal
G05 SendCommand and Wait for Return Status
(used with 9/Series DataHighway PlusCommunication Module)
G05.1-G05.4 Send Command without Waiting for ReturnStatus
(used with 9/Series DataHighway PlusCommunication Module)
G07 18 Programming UsingRadius Values Modal
G08 ProgrammingUsing Diameter Values
G09 00 Exact Stop Non-Modal
G10L2 Setup Work CoordinateOffset Table
G10L3 Setup Tool Management Table
G10L10 Setup Tool Offset Values GeometryTable
G10L11 Setup ToolOffset Values Wear Table
G10.1 Setup Random Tool Table
G10.2L1 Communication Configuration Table
(used with 9/Series DataHighway PlusCommunication Module)
G10.2L2 Output Command Table
(used with 9/Series DataHighway PlusCommunication Module)
G10.2L3 Download Configuration Information
(used with 9/Series DataHighway PlusCommunication Module)
G11 Setup ToolManagement Table (Cancel)
G12.1 21 Spindle 1 Controlling Modal
G12.2 Spindle 2 Controlling
G12.3 Spindle 3 Controlling
G13 00 QuickPath Plus(Use First Intersect.) Non-Modal
G13.1 QuickPath Plus (Use SecondIntersect.)
G14 19 Scaling (Disable) Modal
G14.1 Scaling (Enable)
G15 15 VirtualC (Cancel) Modal
G16.1 VirtualC CylindricalInterpolation
G16.2 VirtualC EndFace Milling
G17 02 Plane Selection Modal
G18 PlaneSelection
G19 PlaneSelection
G90 G77 G20 01 Single PassO.D. and I.D. Roughing Modal
G92 G78 G21 SinglePass ThreadCycle
G94 G79 G24 SinglePass RoughFacing Cycle
G22 04 Programmable Zone2 and3 (On) Modal
G22.1 Programmable Zone 3 (On)
G23 ProgrammableZone 2 and 3 (Off)
G23.1 Programmable Zone (Off)
