To access the scaling magnification data screen, follow these steps:
1. Press the {OFFSET} softkey on the main menu screen.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2. Press the {SCALNG} softkey to display the scaling magnification
data screen. See Figure 13.6.
(softkey level 2)
WORK
CO-ORD
TOOL
WEAR
TOOL
GEOMET
TOOL
MANAGE
RANDOM
TOOL
COORD
ROTATE
SCALNG BACKUP
OFFSET
Figure 13.6
Scaling Magnification Data Screen
REPLCE
VALUE
SCALING MAGNIFICATION
CENTER CURRENT DEFAULT
X +123.00000 2.00000 1.00000
Z +123.00000 2.00000 1.00000
