Basic Control Operation
Chapter 2
2
-
1
7
Program Execute Screen
The following assumes that the steps have been performed to display the
Software Front Panel screen (see page 2-15). Make sure that the function
selected on the Software Front Panel screen is not the Mirror Image nor
the Axis Inhibit feature.
1. Press the {PRGRAM EXEC} softkey.
(softkey level 2)
JOG
AXIS
PRGRAM
EXEC
This screen appears. Before you press this softkey, a program should
have already been selected for automatic execution as described on
page 7-6.
PROGRAM[ MM ] F 0.000 MMPM
Z 0.000 S 0.0
R X 0.000 T 0
C 359.99 FILENAME
SUB NAME
MEMORY MAN STOP
M100;
G90;
Z10;
G70;
BLOCK
RETRCE
JOG
RETRCT
CYCLE
START
CYCLE
STOP
E-STOP
