Manual

Basic Control Operation
Chapter 2
2
-
1
8
2. Select one of these softkey options:
block retrace
jog retract
cycle start
cycle stop
To Perform a: Press:
Cycle Start the softkey that corresponds tothe desiredfeature. Details onthese
features aredescribed inchapter 7.
Cycle Stop the softkey that correspondsto thedesired feature. Details on these
features aredescribed inchapter 7.
Block Retrace the {BLOCK RETRCE} softkey. The controlautomatically
retraces thepreviously executedblock eachtime youpress. The tool
returns tothe start point of BlockRetrace whenyou press the
{CYCLE START} softkey. Details on BlockRetrace canbe found
in chapter 7.
Jog Retract the {JOG RETRCT} softkey. This calls upthe jog retract screen.
Select: the axis, thetype of jog, thespeed multiplyvalue (see
chapter 4), or theHPG number (if HPGhas beenselected asthe
type of jog). Use theup anddown cursor keysto select thefunction,
and the left and right cursor keys toalter the valueassigned tothat
function.
3. Press the {JOG AXES +} or {JOG AXES -} softkeys to select the
direction to jog the axis. Press the exit {Ý} softkey when you
complete the jog retract. The cutting tool automatically retraces the
jog moves you made when you pressed the {CYCLE START}. See
chapter 7.
(softkey level 4)
SET
ZERO
JOG
AXES +
JOG
AXES-
