Important: If tool life management is being used on the system, see the
tool management section in this chapter for details on programming a
T-word. This section assumes that the tool life management feature is not
being used.
Your system installer determines the format for a T-word in AMP.
Table 20.A shows the 6 available format selections.
Table 20.A
T-word Formats
* FORMAT TYPE WEAR OFFSET # GEOMETRY OFFSET #
(1) 1 DGTGEOM + WEAR last digit same aswear
(2) 2 DGTGEOM + WEAR last two digits same aswear #
(3) 3 DGTGEOM + WEAR last three digits same as wear#
(4) 1 DGTWEAR last digit same astool #
(5) 2 DGTWEAR last two digits same astool #
(6) 3 DGTWEAR last threedigits same as tool #
*
For details on which format is being used on a specific control refer to documentation prepared by the system installer.
To use Table 20.A find the format being used on your system. Then go
down the wear offset # column and find which digits of the T-word are
used as the wear offset number. Any other digits to the left of the wear
number are used as the tool number. If there are no digits remaining to the
left of the wear number, the control uses tool number 0. The third column,
geometry offset #, tells if the geometry number is the same number as the
number used for wear or tool. Just because geometry may use the same
offset number as wear it is not necessarily calling the same offset value.
Example 20.1
Using T-word Format #5
T213;
This T-word first callsfor tool number2 to be rotated intoposition, then datais accessed from
the offset tables (chapter3) for valuesunder tool geometryoffset number 2, andtool wear offset
number 13.
20.1.1
Programming a T-word and
Tool Offsets
