Tool Control Functions
Chapter 20
2
0
-
2
5
Example 20.6
Programming Tool Life Management Data
Program Block Description
G10L3; Starts loadingtables.
P1I1Q60; Begins loading datafor tool group1. Type 1(number of uses)
measurement. Threshold 60%.
T1H5D7L25; Places tool 1in group1 withlength offset number of 5, cutter
radius offset number 7, andexpected lifeof 25 uses.
T2H2; Places tool2 ingroup 1 with length offset number of 2, no
cutter radiusoffset number andexpected lifeof 25 uses.
T15H7; Places tool15 ingroup 1with length offset number of 7, no
cutter radiusoffset number andexpected lifeof 25 uses.
P2; Begins loading data for toolgroup 2. Type 0measurement
(default). Threshold at 80% (default).
T12H3D6L40; Places tool12 ingroup 2 with length offset number of 3, cutter
radius offset number of 6, andexpected lifeof 40 minutes.
T13; Places tool 13in group2 withlength andradius offset numbers
of 0 and expected life of 40minutes.
P4I0Q90; Begins loading datafor tool group4. Type 0(time)
measurement. Threshold at 90%.
T20H3D6; Places tool 20in group4 withlength offset number of 3, cutter
radius offset number of 6, andexpected lifeof 0 minutes.
Q50; Resets the threshold at 50% for group4.
G11; Ends the loading operation.
M02;
Backing up tool management tables
This feature causes the control to automatically generate a G10L3 program
that stores all of the information that it finds in the current tool
management table. Any time that this G10 program is executed, it clears
any information that is currently in the management tables and replaces it
with the information that is in the G10 program.
To generate the G10L3 backup program of the tool management tables,
follow these steps:
1. Press the {OFFSET} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
