Example 20.8
Programming Tool Changes Using Tool Life Management.
Example 20.8 assumes that:
- your system installer has configured in AMP the boundary for tool
life management at 100
- the tool changer is located at the secondary machine home point
called by a G30; this is not necessarily true for different machine
applications
- the T-word format is configured as 3 digit geometry + wear
- the maximum allowable T-word format has been set to allow 6-digit
T-words.
Program Block Description
G30X10Z10F.1; Returnto secondaryhome position.
T101000; Change to a group1 tool.
G29; Return from secondaryhome position. Activate toollength
offset usingthe offset number for thetool asassigned inthe
tool management table.
G42; Activate TTRC right usingthe offset number for thetool as
assigned in the tool management table.
END OF CHAPTER
