Manual

Basic Control Operation
Chapter 2
2
-
2
9
Table 2.E (continued)
Password Protectable Functions
Parameter Name: Function becomes accessible when parameter name isin reverse video:
22) SI/OEM MESSAGE · {ENTER MESSAGE} —Enter a new message tobe displayedon thecontrol’spower-up screen.
· {STORE BACKUP} — Storean enteredmessage for thepower-up screento backupmemory.
23) SCALING When SCALINGis not inreverse video, theoperator still hasaccess tothe {SCALNG} softkey; however
values onthe screenmay not bemodified.
24) CHANGE
DIRECTORY
Allows accessto theprotectable directoryfor fileedit, direct execution selection, andencrypted output.
25) AUX COMM Allows accessto the{AUX COMM} softkey that setsData HighwayCommunication ModuleParameters.
26) SEARCHMONITOR Allowsaccess to the {SEARCH MONITOR} softkey that allows searchingand monitoringof the
control’sPAL program.
27) PASS THRU ENABLE Allows access tothe {PT ENABLE} softkeythat enables remoteI/O passthru of AMP, PAL, and other
ODS features. The {PT ENABLE} softkey is onlyavailable whenAMP isconfigured todisallow block
transfers andthe systemcontains remoteI/O hardwarethat has beenenabled throughPAL.
When you power-up, only functions that are not protectable and functions
that are assigned to access level 8 are available (provided that the active
level when power was turned off was not assigned the POWER UP
LEVEL feature). To access the functions that are assigned to a specific
access level, you must enter the password that corresponds to that access
level. To enter a password, follow these steps:
1. Press the {PASSWORD} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2.7.3
Entering Passwords
