Manual

Paramacros
Chapter 28
28-17
Table 28.D (continued)
System Parameters
Parameter # System Parameter Page
5731 to 5743 Home Marker Distance 28-31
5751 to 5763 Home Marker Tolerance 28-31
1
These parameters may only have their value received (read-only)
2
These parameters may only have their value changed (write-only)
#2001 to 9499
Tool Offset Tables
These parameters may be changed or simply read through programming.
The values for these parameters are received or entered into the tool offset
tables for geometry and wear (discussed in chapter 3). NO TAG gives the
parameter numbers associated with each table value.
Table 28.E
Tool Offset Table Parameters
Offset
Number
Parameter # for
Geometry Table
Parameter # for Wear
Table
Tool Length
(Axis 1)
1 to 99 #2701to 2799 #2001 to2099
Tool Length
(Axis 2)
1 to 99 #2801to 2899 #2101 to2199
Tool Length
(Axis 3)
1 to 99 #8501to 8599 #8101 to8199
Tool Length
(Axis 4)
1 to 99 #8601to 8699 #8201 to8299
Tool Length
(Axis 5)
1 to 99 #8701to 8799 #8301 to8399
Tool Length
(Axis 6)
1 to 99 #8801to 8899 #8401 to8499
Tool Radius 1 to99 #2901 to2999 #2201to 2299
Tool
Orientation
1 to 99 #2301 to 2399 N/A
#3000
Program Stop With Message (PAL)
Use this parameter to cause a cycle stop operation and display a message
on line 1 of the CRT. Any block that assigns any non-zero value to
parameter 3000 will result in a cycle stop. The actual value assigned to
parameter 3000 is not used. Parameter 3000 is a write-only parameter.
