Paramacros
Chapter 28
28-22
#5001 to 5012
Coordinates of End Point
These parameters are read-only. They correspond to the coordinates of the
end point (destination) of a programmed move. These are the coordinates
in the work coordinate system.
5001 Axis 1coordinate position 5007 Axis 7coordinate position
5002 Axis 2coordinate position 5008 Axis 8coordinate position
5003 Axis 3coordinate position 5009 Axis 9coordinate position
5004 Axis 4coordinate position 5010 Axis 10coordinate position
5005 Axis 5coordinate position 5011 Axis11 coordinateposition
5006 Axis 6coordinate position 5012 Axis 12coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
#5021 to 5032
Coordinates of Commanded Position
These parameters are read-only. They correspond to the current
coordinates of the cutting tool. These are the coordinates in the work
coordinate system.
5021 Axis 1coordinate position 5027 Axis 7coordinate position
5022 Axis 2coordinate position 5028 Axis 8coordinate position
5023 Axis 3coordinate position 5029 Axis 9coordinate position
5024 Axis 4coordinate position 5030 Axis 10coordinate position
5025 Axis 5coordinate position 5031 Axis 11 coordinate position
5026 Axis 6coordinate position 5032 Axis 12coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
