Manual

Paramacros
Chapter 28
28-23
#5041 to 5052
Machine Coordinate Position
These parameters are read-only. They correspond to the coordinates of the
cutting tool in the machine (absolute) coordinate system.
5041 Axis 1coordinate position 5047 Axis 7coordinate position
5042 Axis 2coordinate position 5048 Axis 8coordinate position
5043 Axis 3coordinate position 5049 Axis 9coordinate position
5044 Axis 4coordinate position 5050 Axis 10coordinate position
5045 Axis 5coordinate position 5051 Axis 11 coordinate position
5046 Axis 6coordinate position 5052 Axis 12coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
Position data for the absolute position of an adaptive depth probe is
invalid.
#5061 to 5069 or #5541 to 5552
Skip Signal Position Work Coordinate Position
These parameters are read-only. They correspond to the coordinates of the
cutting tool when a skip signal is received to PAL from a probe or other device
such as a switch. These are the coordinates in the work coordinate system.
5061 Axis 1coordinate position 5067 Axis 7coordinate position
5062 Axis 2coordinate position 5068 Axis 8coordinate position
5063 Axis 3coordinate position 5069 Axis 9coordinate position
5064 Axis 4coordinate position
5065 Axis 5coordinate position
5066 Axis 6coordinate position
Or if your system has more than 9 axes:
5541 Axis 1coordinate position 5547 Axis 7coordinate position
5542 Axis 2coordinate position 5548 Axis 8coordinate position
5543 Axis 3coordinate position 5549 Axis 9coordinate position
5544 Axis 4coordinate position 5550 Axis 10coordinate position
5545 Axis 5coordinate position 5551 Axis 11 coordinate position
5546 Axis 6coordinate position 5552 Axis 12coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
