Manual

Paramacros
Chapter 28
28-24
#5071 to 5079 or #5561 to 5562
Skip Signal Position Machine Coordinate System
These parameters are read-only. They correspond to the coordinates of the
cutting tool when a skip signal is received to PAL from a probe or other
device such as a switch. These are the coordinates in the machine
(absolute) coordinate system.
5071 Axis 1coordinate position 5077 Axis 7coordinate position
5072 Axis 2coordinate position 5078 Axis 8coordinate position
5073 Axis 3coordinate position 5079 Axis 9coordinate position
5074 Axis 4coordinate position
5075 Axis 5coordinate position
5076 Axis 6coordinate position
Or if your system has more than 9 axes:
5561 Axis 1coordinate position 5567 Axis 7coordinate position
5562 Axis 2coordinate position 5568 Axis 8coordinate position
5563 Axis 3coordinate position 5569 Axis 9coordinate position
5564 Axis 4coordinate position 5570 Axis 10coordinate position
5565 Axis 5coordinate position 5571 Axis 11 coordinate position
5566 Axis 6coordinate position 5572 Axis 12coordinate position
The system installer determines in AMP the name (or word) that is used to
define the axis.
