Manual

Paramacros
Chapter 28
28-25
#5081 to 5089 or #5581 to 5592 Active Tool Length Offsets
These are read-only parameters. They correspond to the currently active
tool length offsets (see chapter 20).
5081 Current axis 1tool lengthoffset. 5087 Current axis 7tool lengthoffset.
5082 Current axis 2tool lengthoffset. 5088 Current axis 8tool lengthoffset.
5083 Current axis 3tool lengthoffset. 5089 Current axis 9tool lengthoffset.
5084 Current axis 4tool lengthoffset.
5085 Current axis 5tool lengthoffset.
5086 Current axis 6tool lengthoffset.
Or if your system has more than 9 axes:
5581 Current axis 1tool lengthoffset. 5587 Current axis 7tool lengthoffset.
5582 Current axis 2tool lengthoffset. 5588 Current axis 8tool lengthoffset.
5583 Current axis 3tool lengthoffset. 5589 Current axis 9tool lengthoffset.
5584 Current axis 4tool lengthoffset. 5590 Current axis 10 tool length offset.
5585 Current axis 5tool lengthoffset. 5591 Current axis 11 toollength offset.
5586 Current axis 6tool lengthoffset. 5592 Current axis 12 tool length offset.
#5095 to 5096
Probe stylus Length and Radius
These parameters correspond to the values set in the probing cycle
parameter table discussed in chapter 27. When values are assigned to these
parameters, the current values in the probe table is replaced.
5095 Probe stylus Length
5096 Probe stylusRadius
For details on probe radius and length parameters, see chapter 27 on tool gauging.
#5101 to 5112
Current Following Error
These parameters are read-only. They correspond to the current following
error for an axis.
5101 Axis1 followingerror 5107 Axis 7following error
5102 Axis2 followingerror 5108 Axis 8following error
5103 Axis3 followingerror 5109 Axis 9following error
5104 Axis4 followingerror 5110 Axis 10following error
5105 Axis5 followingerror 5111 Axis11 followingerror
5106 Axis6 followingerror 5112 Axis 12following error
