Manual

Paramacros
Chapter 28
28-30
#5691 to 5702
Deceleration Ramps for S-Curve Acc/Dec Mode
These parameters are read only. They correspond to the active deceleration
ramps in S--Curve Acc/Dec mode. You can set these parameters by
programming a G48.4 in your part program block. Control Reset, Program
End (M02/M03), or G48 will reset these values to their default AMP values.
For more information about programming G48.x codes, refer to chapter 18 in
your 9/Series CNC Operation and Programming Manual.
5691 Axis 1deceleration ramp 5697 Axis 7deceleration ramp
5692 Axis 2deceleration ramp 5698 Axis 8deceleration ramp
5693 Axis 3deceleration ramp 5699 Axis 9deceleration ramp
5694 Axis 4deceleration ramp 5700 Axis 10deceleration ramp
5695 Axis 5deceleration ramp 5701 Axis 11 decelerationramp
5696 Axis 6deceleration ramp 5702 Axis 12deceleration ramp
#5711 to 5722
Jerk
These parameters are read only. They are only applicable to the current jerk
values when S--Curve Acc/Dec mode is active. You can set these parameters
by programming a G48.5 in your part program block. Control Reset,
Program End (M02/M03), or G48 will reset these values to their default AMP
values. For more information about programming G48.x codes, refer to
chapter 18 in your 9/Series CNC Operation and Programming Manual.
5711 Axis 1 jerk 5717 Axis 7jerk
5712 Axis 2jerk 5718 Axis8 jerk
5713 Axis 3jerk 5719 Axis9 jerk
5714 Axis 4jerk 5720 Axis 10jerk
5715 Axis 5jerk 5721 Axis 11 jerk
5716 Axis 6jerk 5722 Axis 12jerk
