Using a 9/Series Dual--Processing System
3
0
-
2
6
3. Press the {INTERF CHECK} softkey to display the interference
checking data entry screen shown in Figure 30.13.
(
s
o
f
t
k
e
y
l
e
v
e
l
3
)
ZONE
LIMITS
F1-F9 DRLCYC
PARAM
INTERF
CHECK
Figure 30.13
Interference Checking Data Table
SEARCH
NUMBER
REPLCE
VALUE
ADD TO
VALUE
MORE
ZONES
BACKUP
INTERF
INTERFERENCE TABLE
PAGE 1 OF 32
TOOL NO AREA 1 AREA 2
*1 [INCH] [INCH]
X PLUS 1.5000 1.5000
X MINUS -.5000 -1.0000
Z PLUS 1.5000 6.0000
Z MINUS 0.0000 1.5000
<FRONTTURRET>
4. Select a process. Refer to the system installer’s documentation for
details on selecting a process, or press the [PROC SELECT] key.
5. Select a boundary number to enter by using one of these two
methods. Press:
the {MORE ZONES} softkey, or press the [¯] key while holding
down the [SHIFT] key.
the {SEARCH NUMBER} softkey. Enter the desired boundary number
to search for and press the [TRANSMIT] key.
