Manual

Softkey Tree
Appendix A
A-3
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
If you want to: Press:
Edit, activate, or copya program from aperipheral or controlmemory
{PRGRAM MANAGE}
Display orenter tool offset data, the work coordinate systemoffset data, etc.
{OFFSET}
Viewand modify thelocalandglobalparameterassignmentsforparamacros
{MACRO PARAM}
Check the part program, graphics, QuickCheck, and active program without
actually movingan axis
{PRGRAM CHECK}
Enter and display inhibit zone limits, canned cycle parameter data,
communications, AMP, etc.
{SYSTEM SUPORT}
Perform various operations that would normally be done by using an MTB
panel, cycle start, jogging, etc.
{FRONT PANEL}
Display errormessages, including anerror logof old messages
{ERROR MESAGE}
Enter or assignpasswords andaccess levelsto selectedfeatures
{PASSWORD}
Change the language displayed onthe screenof the control
{SWITCH LANG}
Display more softkeys on the same level when there are more softkeys on
a level than canbe displayedat once
{®}
Display theprevious levelor previous rowof softkeys {-}
The remainder of this appendix shows the softkey tree. This tree illustrates
the entire softkey layout on the control in an easy-to-use flow-chart type
format. This flow chart has been drawn to have no 4-way intersections (no
4 lines connected at any one point). If you see what appears to be a 4-way
intersection, it is really only a crossover point for lines that do not
intersect.
Describing Level 1 Softkeys
Using the Softkey Tree
