Manual

OffsetTables and Setup
Chapter 3
3-12
Tool offset range verification checks:
the maximum values entering the tool offset tables
the maximum change that can occur in either table
To use tool offset range verification, follow this softkey sequence:
1. Press the {SYSTEM SUPORT} softkey.
(softkey level 1)
PRGRAM
MANAGE
OFFSET MACRO
PARAM
PRGRAM
CHECK
SYSTEM
SUPORT
FRONT
PANEL
ERROR
MESAGE
PASS-
WORD
SWITCH
LANG
2. Press the {AMP} softkey.
(softkey level 2)
PRGRAM
PARAM
AMP DEVICE
SETUP
MONI-
TOR
TIME
PARTS
PTOM
SI/OEM
SYSTEM
TIMING
3. Press the {AXIS PARAM} softkey.
(softkey level 3)
AXIS
PARAM
PATCH
AMP
UPDATE
BACKUP
UPLD/
DWNLD
BACKUP
AMP
4. Press the {RANGE PARAM} softkey.
(softkey level 4)
SPNDL
PARAM
SERVO
PARAM
AXIS
CALIB
HOME
CALIB
REVERS
ERROR
RANGE
PARAM
3.1.5
Tool Offset Range
Verification
