Appendix
B
B-1
Error and System Messages
This appendix serves as a guide to error and system messages that can
occur during programming and operation of the 9/Series control. We listed
the messages in alphabetical order along with a brief description.
Important: To display both active and inactive messages, press the
{ERROR MESAGE} softkey found on softkey level 1. For details, see
chapter 2.
Important: This appendix covers only error and system messages.
PAL-generated operator messages generally appear on lines 21 and 22 of
the CRT and should be described in documentation prepared by the
machine tool builder.
Message Description
Symbols
(+) 15V SUPPLY FAILURE + 15Vdc isnot available at themain processor board. Check thewires from themain power
supply andconnector CN07 on themain processor board.
(--) 15V SUPPLY FAILURE -- 15 Vdcis not availableat the mainprocessor board. Check the wiresfrom themain power
supply andconnector CN07 on themain processor board.
(+) OVERTRAVEL PROGRAM ERROR If axismotion continuesalong theprogrammed path, theindicated axiswill reachor exceed the
positive software overtravel limit (runtimeerror).
(--) OVERTRAVEL PROGRAMERROR If axismotion continuesalong theprogrammed path, theindicated axis will reachor exceed the
negative software overtravel limit (runtimeerror).
(+) OVERTRVLPRGRAM ERROR: Theend-point of the commandedmove willcause theindicated axisto reach or exceedthe
positive software overtravel limit (pre-executionerror).
(--) OVERTRVL PRGRAMERROR: The end-point of thecommanded move will causethe indicatedaxis toreach orexceed the
negative software overtravel limit (pre-executionerror).
+/-- SIGN ERROR A + or -- sign was found out of placewhen anumeric valuewas beingdecoded. Check the
active program block for programmingformat errors.
1
1394 AXIS MODULE MISMATCH At power turn onthe system identifiedan axismodule inthe 1394 rack that ismisconfigured in
AMP. If an extraaxis module is present in the 1394 rack it should eitherbe fully configured or
not configured at all in AMPeven if that axismodule isnot used or detached.
1394 RING COMMUNICATIONS ERROR At power up theinternal communicationsring whichruns throughthe front of the1394 system
and drive modules waseither not connected, adevice onthe ringexperienced ahardware
failure, or adevice onthe ringwas discoveredto bemisconfigured oncea commandwas sent to
the device. Make sureall axis modulesand theend terminator are properlyconnected to
complete the communication ring.
1746 RACK CARDS MISMATCH The I/Oconfiguration for the1746 I/Orack that wasdownloaded from ODS, orresides inthe
PAL PROMs, contradicts what isactually inthe rack(devices must matchslot-for-slot).
1771 RACK CARDS MISMATCH The I/Oconfiguration for the1771 I/Orack that wasdownloaded from ODS, orresides inthe
PAL PROMs, contradicts what isactually inthe rack(devices must matchslot-for-slot).
