Manual

Error and System Messages
Appendix B
B-7
Message Description
CANNOT RENAME When performing a rename of aprogram name, the newprogram name hasnot been correctly
entered. The format is OLDPROGRAM NAME,NEWPROGRAM NAME.
CANNOT REPLACE STARTPOINT An illegal attempt was madeto changethe axiscalibration start-point usingthe onlineAMP
feature.
CANNOT RESTART G24HARD STOP An attempt was madeto restart a part program ona blockwhich wouldhave anaxis at thehard
stop. You cannot restart or midstart a part program afterif (at that blocks execution) anyaxis
would be holding against a hardstop. You must either re-start/mid--start to a blockbefore the
G24 hard stop block or toa blockafter the hardstop isreleased.
CANNOT SEND AVAILABLE COMMAND Thisis displayedwhen anon-programmed communicationscommand isexecuted from
“send’¨softkey.
CANNOT SET DATA WHEN TOOL ISACTIVE An attempt was madeto manually (using thesoftkeys) changetool management data forthe
currently activetool. Tool management datacan bechanged onlyfor atool that is not currently
selected as the activetool.
CANNOT TAPIN CSS You must disable the CSS feature beforeyou begina tappingoperation. Disable CSS usinga
G97 command.
CANNOT TAPIN VIRTUAL-C MODE Youattempted touse thesolid tappingfeature while cylindrical orend-face millingwas active.
CANNOT UPLOAD - PAL NOTIN PROM PAL can be uploaded only from thePAL PROMs. PAL inRAM memory cannot beuploaded.
CANNOT UPLOAD - PAL SOURCE NOTLOADED Whenthe sourceis loaded, PAL canbe uploadedin the9/240 only. The 9/260and 9/290
always havePAL inflash.
CANNOT USE COPY WITH ACTIVETOOLOFFSET An attempt was made tocopy offset data from one axisto another usingthe {COPYOFFSET}
softkey. You cannot usethis softkeyif the tooloffsetsare active.
CANNOT USE EXIT -BLOCK NOTFOUND An attempt wasmade to{EXIT} while searchingfor ablock for amid-program start. You cannot
use {EXIT} until the block has beenfound. To abort the search, use {QUIT}.
CANNOT WRITE A READ-ONLY PARAMETER An attempt was made toassign a value to a PAL or system paramacroparameter that is a
read-only parameter. The value of these parameters canbe used only bythe programmer; they
cannot be altered in the program.
CANNOT WRITE TOPROGRAM Thisindicates aserious problem withthe program. Attempt to writeto programa secondtime.
If retry doesn’t work, youmay haveto deletethe program. Typically this error isnot caused by a
programmer or operator action, but ratherby aninternal program softwareerror.
CAUTION! YOU ARE IN7300 TAPE MODE
TORETURN TO STANDARD 9/240MODE
RESET THE 7300--COMPATIBILITY PAL FLAG
The operator is cautioned that the tapebeing copiedis presumed to bea 7300formatted tape.
This messageis displayedon thecopy-tape set-upscreen whenthe MCUis in7300
compatibility mode.
CC/TTRC ON, CAN’TASSIGN TIMEDEP. PARAM An attempt wasmade toassign atime-dependent paramacro system parameter while
dresser/wheel radiuscompensation wasactive. Time-dependant parametersare any system
parameters that recordor reference a current axisposition.
CHAMFER LENGTH/RADIUSTOOLARGE A chamfer or radius valueprogrammed with a,C or ,Rwould generatea chamfer or radiusthat
is largerthan oneor bothof the twoadjacent tool paths.
CHAMFER/RADIUS NOTALLOWED Anattempt was made to perform achamfer or radius cut (programmedwith a,R or ,C)in a
block that doesnot allow thesefunctions tobe performed. For example, you cannot doa
chamfer or radiuscut in anon-motion block, inthe last blockon anMDI line, or in the last block
of a part program.
CHANGE NOTMADE IN BUFFEREDBLOCKS Changes to the offset table didnot affect thoseprogram blocks that werealready inthe control’ s
current activation queue. Program blocks that callfor offsetsand whichfollow thosealready in
the activation queue will call theupdated offset tables.
CHANNEL NAME TOOLONG Thereis anerror in G05DH+ communicationsblock.
CHAR MUSTBE _, ., LETTER, DIGIT Youhave usedincorrect search stringsyntax inthe PAL searchmonitor utility.
CHAR MUSTBE LETTER,DIGIT, UNDERSCORE You haveused incorrect searchstring syntaxin thePAL searchmonitor utility.
CHARACTERS MUSTBE DIGIT You haveused incorrect searchstring syntaxin thePAL searchmonitor utility.
