Manual

Error and System Messages
Appendix B
B-9
Message Description
CPU #2HARDWAREERROR #4 The 68030main processorhas detectedan illegaladdress. Consult Allen-Bradley customer
support services (9/290only).
CPU #2HARDWAREERROR #6 The 68030main processorhas detecteda privilegeviolation. Consult Allen-Bradley customer
support services (9/290only).
CPU #2HARDWAREERROR #8 CPU #2has detectedan unassignedvector interrupt. Consult Allen-Bradley customersupport
services (9/290only).
CPU #2HARDWAREERROR #9 CPU #2has detectedan illegalinstruction. Consult Allen-Bradley Customer Support Services
(9/290 only).
CPU #2LOCAL RAMFAILED The RAM memory supporting the 68030I/O ringprocessor has failed(Z80 I/Oring processor on
9/240 only). Consult Allen-Bradley customer support services.
CPU #2PROM HAS FAILED ThePROM memory supportingthe 68030(Z80 9/240only) I/Oring processor hasfailed its
checksum test. Consult Allen-Bradley customer support services.
CPU #2RAM HAS FAILED TheRAM memory supportingthe 68030(Z80 9/240only) I/O ring processor hasfailed. Consult
Allen-Bradley customersupport services.
CPU #2WATCHDOG ERROR The 68030(Z80 9/240only) I/Oring processor hasfailed. Consult Allen-Bradley customer
support services.
CREATING BACKUP FILE- PLEASE WAIT A backup filefor the current utilityis beingcreated. The message will clearwhen thebackup is
complete.
CREATING TOOL OFFSETFILE - PLEASE WAIT Thetool offset table (or tables) iscurrently beingbacked-up. The control is generatingan
executable G10 program andentering it intothe control’ s program directory.
CREATING TOOL MGMT. FILE -PLEASE WAIT The toolmanagement tables arecurrently being backed-up. The controlis generatingan
executable G10 program andentering it intothe control’ s program directory.
CSS RPM LIMITAUXILIARYSPINDLE 2 The auxspindle 2RPM requested by CSS isgreater than themaximum CSS RPM limit. This
limit is set bythe systeminstaller inAMP or can be reduced by programming a G92 block.
CSS RPM LIMITAUXILIARYSPINDLE 3 The auxspindle 3RPM requested by CSS isgreater than themaximum CSS RPM limit. This
limit is set bythe systeminstaller inAMP or can be reduced by programming a G92 block.
CSS RPM LIMITFIRST SPINDLE The spindle1 RPMrequested by CSS isgreater than themaximum CSS RPM limit. This limit is
set by thesystem installer inAMP or canbe reducedby programminga G92block.
CSS RPM LIMITPRIMARYSPINDLE The primaryspindle RPMrequested by CSS isgreater than themaximum CSS RPM limit. This
limit is set bythe systeminstaller inAMP or can be reduced by programming a G92 block.
CSS RPM LIMITSECOND SPINDLE The spindle2 RPMrequested byCSS isgreater than themaximum CSS RPM limit. This limit is
set by thesystem installer inAMP or canbe reducedby programminga G92block.
CSS RPM LIMITTHIRD SPINDLE The spindle3 RPMrequested byCSS isgreater than themaximum CSS RPMlimit. This limit is
set by thesystem installer inAMP or canbe reducedby programminga G92block.
CUR LOOPG/A CLOCK LOST This errorwas generatedby aservo amplifier error. It can usually becorrected byturning off
power tothe amplifier, and thenback on.
CURRENT FEEDBACK ERROR The servomodule hasdetected faultyor missingcurrent feedback from thedigital servo motor.
The most likely cause of thiserror isbe abroken or disconnectedwire.
CURSORING NOT ALLOWED While assigning a {CUSTOM TOOL} in {RANDOMTOOL}, youcannot cursor to select another
tool position.
CUTTER COMP./TTRC INTERFERENCE Thecutter radius istoo large, reversemotion isrequired, or some other cutter compensation
interference exists. Either an alternatetool or analternate toolpath must beprogrammed.
Another optionwould beto disablecutter compensation error detection.
CYCLE ALREADYACTIVE An attempt was made tostart a cyclewhile another cycle wascurrently executing.
CYLINDER RADIUSIS ZERO Thecylinder radius wasnot programmed ina virtualC cylindricalinterpolation (G16.1) cycle.
CYLINDRICAL AXIS NOT PRESENT Cylindrical interpolationwas programmedwithout at least one cylindricalinterpolation axes
present (rotary, park, or feed axes).
