Manual

Error and System Messages
Appendix B
B-14
Message Description
EXTRA KEYBOARDOR HPGON I/O RING The control detecteda keyboard or HPGon the9/Series fiber opticring that wasnot configured
as aring device. The I/O ring will still functionand thecontrol willNOT beheld inE-Stop. You
may alsouse thekeyboard orHPG by selecting it asthe active device via the corresponding
PAL flags. You shouldconfigure thekeyboard or HPGwith theI/O assignerutility (Seeyour
9/Series PAL referencemanual for details).
F
FCM DUALPORT RAM FAILURE The FCM detectedan error indualport RAM.
FCM FLASHRAM FAILURE The FCM detected anerror in flashRAM.
FCM LOCALRAM FAILURE The FCMdetected anerror inlocal RAM at power-upor during theruntime diagnostics.
FCM PLUGCONFIGURE FAILED The FCM cardfailed toconfigure correctly.
FCM PLUGFAULT The plugon theFCM detected anerror.
FCM PLUGNEGOTIATE FAILED The FCM firmwarecould not communicatewith theplug.
FCM POWERUP SEQUENCE FAILURE Power-upfailed. Tryagain. If error appears again, contact yourAllen-Bradley sales
representative.
FCM REVISIONCHECK FAILURE Revisionon moduleis out-of-date. Contact Allen-Bradley salesrepresentative toget latest
revision of the module’ s firmware.
FCM ROM FAILURE TheFCM detected anerror inROM during runtimediagnostics.
FCM SHADOW RAMFAILURE The FCM detected anerror in shadowRAM.
FCM SPURIOUS INTERRUPT A spuriousinterrupt occurred onthe FCM card.
FCM VRTX ERROR A call from VRTX from theFCM card firmware returned an error.
FCM WATCHDOG The watchdogon theFCM card timedout.
FDBK NOTAVAILABLE ON4TH AXIS OFBOARD An attempt wasmade toreceive feedbackfrom the axisthat is configuredas thefourth axison a
servo board. You canonly receive feedback from thefirst three axeson aservo board.
FEEDBACK DISCONNECTED The controlhas detecteda lossof feedback from theencoder. The most likely cause of this
error wouldbe abroken or disconnectedwire. Axis homingwill berequired after theerror
condition is corrected.
FEEDBACK OPTIONNOT INSTALLED A PTO checkdetermines thelegal number of axes.
FEED AXISDATA NOTPROGRAMMED Feed axisdata requiredduring agrinder fixed cycle was not programmed.
FEED AXISMOTION NOTALLOWED During Virtual Cprogramming, no axismotion isallowed onthe axisspecified asthe feedaxis in
AMP.
FEED TO HARDSTOP PROGRAMMING ERROR No axis, or morethan oneaxis, was programmedin aG24 block. Or the programmedaxis
integrand was not programmed inthe block.
FILE CANNOTBE CONVERTED TOEIA FORMAT The filerequested tobe output toa devicehas charactersthat cannot be convertedto EIA.
FILE DOWNLOADCOMPLETE Status message that means the downloadhas completed.
FILE DOWNLOADERROR Check filedownload andfile downloadconfiguration screensto makesure allfields areentered
correctly.
FILE DOWNLOADIN PROGRESS This statusmessage meansa fileis beingdownloaded.
FIXED CYCLEALREADY ACTIVE Youcannot program a fixed cyclewith afixed cyclealready active.
FIXED CYCLEPROGRAMMING ERROR A fixedcycle hasbeen programmedincorrectly. Verify that thecorrect parameters havebeen
used and that parameters restrictedto integeror positivevalues are programmed assuch.
FLASH INUSE -- TRY AGAINLATER Only onetask isallowed towrite flashat a time. If a secondtask requestsa flashwrite, you will
see this message.
FLASH SIMMSARE NOTINSTALLED Installthe flashSIMMs intothe 9/Seriesmother board. Flash SIMMsmust be installed. If a
repaired system is being installed, you shouldhave savedyour flash SIMMsfor re-installation
before making the return.
