Manual

Error and System Messages
Appendix B
B-18
Message Description
ILLEGAL DUAL CONFIGURATION Both dual masteraxes nameshave thesame letterOR whenassigning dualgroups inAMP,
dual groupsmust be assignedin contiguousorder, starting with group 1, 2, 3, 4, and 5. You can
not assign axes to dualgroup 3without axes havingbeen assignedto dualgroups 1and 2.
ILLEGAL DUAL LINEAR/ROTARY CONFIGURATION The dual group cannot containa mixtureof linear androtary axes.
ILLEGAL FILENAME An attempt was madeto createa program using aprogram name that containsillegal
characters. A different program namemust be used.
ILLEGAL G40 EXIT BLOCK An illegalsequence of exit moveswas programmedin aG40 exit block.
ILLEGAL G88.5 OR G88.6PARAMETERS Illegal parameters wereentered ina G88.5or a G88.6 programming block.
ILLEGAL G99 Anillegal G99was enteredin aprogramming block.
ILLEGAL G-CODE IN INTERRUPTMACRO Anillegal G-code has been programmed in a program calledby aprogram interrupt. G24, G25,
G26, G40, G41, G42, G52, G92, and G92.1 cannot be programmed inan interrupt program.
ILLEGAL G-CODE IN POCKET An illegalG-code wasentered ina G88or G89 pocket-programmingblock.
ILLEGAL I/O RING DEVICE CODE There isa deviceon theI/O ringthat cannot be identified.
ILLEGAL I/O RING RACK SLOT CODE There isa card in the 1771I/O rackthat the I/Oring cannot use.
ILLEGAL INPUT A numberwas input from thekeyboard insteadof a character, ora character was input instead
of a number.
ILLEGAL MACRO CMD VIAMDI Aparamacro commandthat cannot be usedin MDI modewas programmed. This alsocan
include an illegal sub-programreturn M99code.
ILLEGAL MASTER AXIS NAME Slave axesthat do not havea master havebeen configuredfor a dual group ORyou have
assigned a $ axis name asa group master. Axis names beginningwith a $ can not beassigned
as themaster axis fora dual group (first logicalaxis assignedto thegroup).
ILLEGAL PALPRIORITY MESSAGE Thiserror message displayseach timeyour PAL logicprogram attempts tosave amachine
error messagethat contains dynamic datain the error log. Contact your system installer for
assistance with this problem.
ILLEGAL PASSWORD A password wasentered that wasnot assigned toone of the 8 different password levels. Make
sure that no one has changed thepasswords byusing {ACCESSCONTRL}.
ILLEGAL PLANE -- USING SLAVE AXIS Thisis a power turn-on message. When usingdual axes, oneof the slaveaxes wasAMPed as
part of the plane configuration. Only master canbe usedin theplane configuration.
ILLEGAL PLANE DEFINITION The axisplane assignment madein AMPis incorrect. It can alsooccur if the two axes assigned
to a plane have thesame axisname.
ILLEGAL PROGRAMMED RETURN GROUP The toolgroup programmedin anM06 blockmust be thecurrently activetool groupthat is being
replaced (not the tool groupyou arechanging to). This requirement is configuredin AMPby the
system installer.
ILLEGAL PROGRAMMED RETURN TOOL Thetool number programmedin anM06 blockmust be thecurrently activetool number that is
being replaced (not the tool number you are changingto). This requirement isconfigured in
AMP bythe system installer.
ILLEGAL RANDOM TOOLTABLE ASSIGNMENT An attempt wasmade toprogram a G10.1L20block that wouldassign atool toa toolpocket that
already hasa toolassigned toit.
ILLEGAL RECIPROCATIONINTERVAL The programmedreciprocating intervalis greater thanthe totalrollover distance.
ILLEGAL ROTATION PLANESELECTED Whenusing theexternal part rotationfeature, the externalpart rotation planeselected onthe
rotation parameter screen isnot the currentlyactive planein theprogram block beingexecuted.
ILLEGAL SPINDLE PROCESS NUMBER An illegal process number wasused to indicate a processthat uses one of the spindles.
INCOMPATIBLEPAL SOURCE The PALsearch monitor utility can not be accessed. The PAL searchmonitor utility requires
PAL program built witha newer versionof ODS.
