Manual

Error and System Messages
Appendix B
B-22
Message Description
INVALID PROGRAM NUMBER (P) A program number calledby asub-program or paramacrocall is invalid. A P-wordthat calls a
sub-program or paramacrocan onlybe anall-numeric program nameas manyas 5digits long.
The O-word preceding the numeric programnumber incontrol memory cannot beentered with
the P-word.
INVALID REMOTE NODE NAME An error occurredin G05DH+ communicationsblock.
INVALID REMOTE STATION TYPE An erroroccurred inG05 DH+communications block.
INVALID REPEAT COUNT(L) An L parameter that programsthe number of timesa paramacroor other operationis tobe
repeated was programmed incorrectlyor out of thelegal range. The L-word for repeat count
must be a whole, positive number. Decimal values andnegative values are invalid. The
maximum valueof an L-wordis 9999.
INVALID ROUGHING CYCLE(P/Q) WORD VALUE When executing a roughing cycle, the starting or endingsequence number of thecontour
defining blocks cannot be foundin thecurrently executingprogram. The sequence number of
the contour blocks is programmedusing the P andQ words. These blockscan beanywhere in
the program provided theyare resident inthe sameprogram, sub-program, or paramacro
program that containsthe callingblock.
INVALID SCALE FACTOR(P-WORD) Aninvalid scalefactor has beenspecified. The P-wordhas arange of 0.0001to 999.99999.
INVALID SERVOHARDWARETYPE TheAMP servoparameter that selects theservo typedoes not matchthe hardwarefound on
the control when theAMP fileis downloaded. Either AMP ismisconfigured or theservo
hardware installed on your system is not correctlyinstalled or not of thecorrect type.
INVALID SHAFT POCKET When enteringa custom toolin therandom tool table, anattempt was madeto assigna shaft
pocket position that is not in therange of thenumber of pocketsassigned tothe tool. The shaft
pocket number must beequal to or less than the number assignedfor the numberof pockets.
INVALID SHAFT POCKETVALUE A program isattempting toenter acustom tool inthe random tooltable witha invalidshaft
pocket position (not in the range of thenumber of pockets assignedto thetool). The shaft
pocket number must beequal to or less than the number assignedfor the numberof pockets.
The shaft pocket value is assignedin aG10.1 block following theR-word.
INVALID SPCMD VALUE A invalidspecial commanderror typically occurswhen theservo PROMsare not compatible
with the main processor PROMs. Check thesoftware versionnumbers andcontact
Allen-Bradley customersupport services.
INVALID SYMBOL NAME An error occurredin G05DH+ communicationsblock.
INVALID T-CODE FORMAT Thisis aninvalid T-Code Format
INVALID_THREAD_ANGLE Anattempt was made to program anangle that isoutside theallowable range, whichis 0
through 120 degrees.
INVALID THRESHOLD RATE An invalidthreshold percentagewas enteredfor a toolgroup while setting tool management
data. The thresholdpercentage must rangebetween 0and 100percent. Only wholepositive
numbers canbe entered. If using a G10 block, the thresholdpercentage isentered witha
Q-word.
INVALID TIME FORMAT MUSTBE HH:MM:SS An invalidtime format was entered. The time format must be hour / minute / second
(HH/MM/SS).
INVALID TOOLAXIS This isan invalidTool Axis.
INVALID TOOLCUTTER COMPENSATION NUMBER An attempt wasmade toenter a toolradius offset number, for cutter compensationor TTRC, in
the tool life management tablethat is larger thanthe maximum offset number allowed. If the
tables arebeing loadedby aG10 program, theradius offset is enteredwith aD-word inthe
block.
INVALID TOOLDIAMETER VALUE Aninvalid tooldiameter value was entered ina program block.
INVALID TOOLGROUP An attempt was made tocreate atool groupgreater than 200 in the tool management tables. A
maximum of 200tool groups canbe used. If loading the tables using aG10 program, the tool
group number is entered using aP-word.
