Message Description
INVALID TOOLLENGTH OFFSETNUMBER Anattempt was madeto enter atool lengthoffset number inthe toollife management tablethat
is largerthan themaximum offset number allowed. If the tablesare beingloaded bya G10
program, the length offset number is enteredwith aH-word inthe block.
INVALID TOOLLIFE TYPE Anattempt was madeto enter aninvalid toollife typefor a tool group inthe toolmanagement
tables. Valid toollife typesare type0, 1, or 2.
INVALID TOOLNUMBER Either no toolor an invalidtool number wasprogrammed in a random tool G10.1 block. Tools
should be programmed with aQ-word ina G10.1block or withina rangedetermined bythe
system installer inAMP. An invalidtool number wasentered intothe toolmanagement tables or
was programmedin apart program block.
INVALID TOOLNUMBER FROM PAL ThePAL offset change featurespecified aninvalid toolnumber to thecontrol.
INVALID TOOLORIENTATION This is aninvalid toolorientation.
INVALID TOOLTABLE TYPE Thisis aninvalid tooltable type.
INVALID VALUE ZONE3 A zone3 valuewas enteredthat is outside of the zone3 limits.
INVALID VALUE ZONE3: The zone listed has values that areoutside of thezone limits.
INVALID VELOCITY FDBK TYPE AMP for your digitaldrive system hasbeen configuredfor an invalid velocity loophardware type.
Valid values fordigital systemsare NOFEEDBACK, ABSOLUTE FEEDBACK, and
INC ENCODERON DIGITAL MODULE. Other selections areinvalid ondigital systems.
INVALID WHEEL ANGLE An invalidwheel anglehas beenentered for theangled wheel grinder. Wheel anglesmust be
entered between 0 and 180degrees. Also wheelangles that approach90 degreesare also
invalid.
INVALID WORD ING10L3 MODE Anattempt was madeto assigna parameter that isnot a legalparameter in the G10L3 mode.
G10L3 assigns data tothe toolmanagement tables.
INVALID WORD ING11 BLOCK An invalidword wasprogrammed ina G11 blockthat cancels thedata settingmode forthe tool
management tables. The G11 codemust be programmedin ablock that containsno other data.
INVALID ZONE LIMIT Thisis aninvalid ZoneLimit.
INVALID ’,’ WORD A word otherthan achamfering C-word, a radius R-word, orQPP angleword wasprogrammed
in a block with acomma “,”. Only theradius and chamfer words canbe precededwith a“,” ina
block.
IPD ANDG16.3/G16.4 CANNOTBE CONCURRENT Thiserror message isissued whenin-process dressingis onand ablock containinga G16.3or
G16.4 is activated ona cylindricalgrinder inangled wheelconfigurations.
J
JOG WILL CAUSE (+) OVERTRAVEL Anattempt was madeto executean incrementaljog that would move the indicatedaxis beyond
its positivesoftware overtravellimit.
JOG WILL CAUSE (-) OVERTRAVEL An attempt was made toexecute an incremental jogthat would movethe indicatedaxis beyond
its negativesoftware overtravellimit.
JOGGED HOMETOOFAST: The speedselected for themove tothe homelimit switch istoo fast andthe homingoperation
has failed. Move theaxes backto theother sideof the limit switch(the sidebefore thehoming
operation began), and re-execute the homingoperation, this time slowing the speed usingthe
<SPEED/MULTIPLY>switch or the <FEEDRATE OVERRIDE> switch.
L
L VALUEOUT OF RANGE AnL-word repeat count wasprogrammed larger thanthe system iscapable of performing
(typically amaximum L of 9999 ispermitted). A second blockwill needto beprogrammed to
duplicate the commands again. Enter asmaller L-word for bothblocks.
L-WORD CANNOTBE GREATER THAN TOOL RADIUS The programmedL-word valuein aG88.5 or G88.6hemispherical pocket cycleis greater than
the programmed tool radius. The incrementalplunge depth of a hemispherical pocket cycle
cannot be greater than thetool radius.
L- WORDOUT OFRANGE More than1000 spark-out passeswere specifiedby theL-word ina grinderfixed cycle.
