Message Description
LARGER MEMORY - REFORMAT This message typically occurs after anew AMPor PAL hasjust been downloadedto thecontrol.
There is now morememory availablefor the RAMdisk, but you needto reformat touse it. If
desired, you do not have to reformat RAM andcan continueto runthe controlwith theRAM disk
at its current size.
LEAD WORDFORMAT FINERTHAN The word format programmed is requesting afiner resolutionthan theaxis wordformat for the
corresponding axis allows. These word formats areset in AMP.
LENGTH OFFSETAXIS MISSINGIN PROCESS You haveconfigured thetool lengthaxis asa sharedaxis andit is currentlynot being controlled
by theprocess requestingto activatea toollength offset. The shared length axis must be
returned to the process attempting toactivate the tool offset. Or tool offsets were programmed
for anaxis that is configuredin AMP as unfitted.
LESS MEMORY - REFORMAT This messagetypically occursafter a newAMP or PAL hasjust been downloadedto thecontrol.
There is now lessmemory availablefor the RAMdisk, and youmust reformat to usethe RAM
disk.
LETTER ORDIGIT MUSTFOLLOW $, %, !, &, OR# Youhave usedincorrect search stringsyntax inthe PAL searchmonitor utility.
LETTER ORDIGIT MUSTFOLLOW $, %, ! OR# Youhave usedincorrect search stringsyntax inthe PAL searchmonitor utility.
LETTER ORDIGIT MUSTFOLLOW $, %OR ! You have used incorrect search stringsyntax in the PAL searchmonitor utility.
LETTER ORDIGIT MUSTFOLLOW $, %OR ! You have used incorrect search stringsyntax in the PAL searchmonitor utility.
LETTER ORDIGIT MUSTFOLLOW # Youhave usedincorrect search stringsyntax inthe PAL searchmonitor utility.
LIMIT EXTRN DECEL SPEEDON Dual axeshave limitedthe externaldecel speedAMP value. An axisin thedual-axis groupwas
AMPed with a lower value.
LIMIT MANUAL DLY CONSTNT ON Dualaxes havelimited themanual delay constant AMPvalue. An axisin thedual-axis group
was AMPedwith alower value.
LIMIT MAX CUTTING FEEDON Dualaxes havelimited themaximum cutting feedrate AMP value. An axisin thedual-axis group
was AMPedwith alower value.
LIMITED ACC/DECRAMP ON Dualaxes havelimited theacc/dec ramp AMP value. An axisin the dual-axis groupwas
AMPed with a lower value.
LIMITED RAPIDFEEDRATE ON Dualaxes havelimited therapid feedrateAMP value. An axisin thedual-axis group was
AMPed with a lower value.
LIMITED VELOCITYSTEP ON If the velocitystep AMPvalue isnot the samefor all axesof a dualgroup, the controlwill adjust
them tothe limitingaxis.
LOW VOLTAGE ONFLASH STICKS Call Allen-Bradley Support Services.
LOWER >UPPER A valueentered inthe programmablezone tablefor zone 2or 3results in a lower limit value
being greater than theupper limit. The upperlimit must always begreater than the lower limit.
M
M02 OR M30 FOUND- REQUEST TERMINATED This erroroccurs if anM02 or M30is foundbefore therequested blockwhile searching during a
mid-program start. The searchwill beterminated at theM02/M30 block.
MACHINE HOMEREQUIRED ORG28 An attempt wasmade toprogram an axismove beforethe axeswere homed. Axes canbe
homed manually or by programminga G28 block.
MASTER HASTOBE AMPEDFIRST The dualmaster axis hasto beconfigured first inthe AMPdata base.
MASTER ONLY G-CODE -- MUST PARK SLAVES An attempt wasmade toprogram a G-codethat is not compatiblewith adual axes. The
programmed G-code can only be appliedto the AMP definedmaster axis of thedual axisgroup.
All other axesin the dual axisgroup must beparked.
MATH OVERFLOW Your paramacroor calculator function is requiring acalculation withan excessively large or
illegal value.
MAX SIZEEXCEEDED The programmednumber of symbols istoo large (the communication datapacket is too large).
MAX SOLIDTAP RPM EXCEEDSMAX GEAR RPM The resultingsolid tapingRPM exceeds thespindles current RPM Maximumfor theactive gear
range. Either change gear ranges, or reducethe tappingspeed.
