Manual

Error and System Messages
Appendix B
B-26
Message Description
MINIMUM RPM LIMITAUXILIARYSPINDLE 2 Thecommanded auxspindle 2speed requestedby thecontrol is lessthan the AMPed minimum
aux spindle2 speedfor thecurrent gear being used. This requiresa gear changeoperation ora
change in the programmed aux spindle2 speed. In somecases, the <SPINDLE SPEED
OVERRIDE> switch may besufficient.
MINIMUM RPM LIMITAUXILIARYSPINDLE 3 Thecommanded auxspindle 3speed requestedby thecontrol is lessthan the AMPed minimum
aux spindle3 speedfor thecurrent gear being used. This requiresa gear changeoperation ora
change in the programmed aux spindle3 speed. In somecases, the <SPINDLE SPEED
OVERRIDE> switch may besufficient.
MINIMUM RPM LIMITFIRST SPINDLE Thecommanded spindle1 speedrequested by the controlis lessthan theAMPed minimum
spindle 1 speed for the current gear beingused. This requiresa gearchange operationor a
change in the programmed spindle1 speed. In somecases, the <SPINDLESPEED
OVERRIDE> switch may besufficient.
MINIMUM RPM LIMITPRIMARYSPINDLE The commandedprimary spindlespeed requestedby thecontrol is lessthan the AMPed
minimum primaryspindle speedfor the current gear beingused. This requires agear change
operation or a changein theprogrammed primaryspindle speed. In somecases, the
<SPINDLE SPEEDOVERRIDE> switchmay besufficient.
MINIMUM RPM LIMITSECOND SPINDLE The commandedspindle 2speed requestedby thecontrol isless thanthe AMPedminimum
spindle 2 speed for the current gear beingused. This requiresa gearchange operationor a
change in the programmed spindle2 speed. In somecases, the <SPINDLESPEED
OVERRIDE> switch may besufficient.
MINIMUM RPM LIMITTHIRD SPINDLE The commandedspindle 3speed requestedby thecontrol is lessthan the AMPed minimum
spindle 3 speed for the current gear beingused. This requiresa gearchange operationor a
change in the programmed spindle3 speed. In somecases, the <SPINDLESPEED
OVERRIDE> switch may besufficient.
MIRROR NOTALLOWED ONROLLOVER AXIS Youcannot perform mirrored motionusing anaxis withrollover.
MISSING 1394 I/O RING ADDR This messageindicates that a1394 amplifierID hasbeen AMPedbut not defined inI/O ring
assignment from ODS. The 1394amplifier must be adefined deviceon the9/Series fiberoptic
I/O ring.
MISSING ( [ ) AFTER FUNCTIONNAME Paramacroand calculator functionsmust have their valuesenclosed in [ ], for example, SIN[5].
MISSING ( ] ) Paramacroand calculator functionsmust have their valuesenclosed in[ ], for example, SIN[5].
The control has foundthat a right bracket “]”is missingin thecurrent operation.
MISSING (END) COMMAND Thecontrol has foundan end-of-programblock (M02or M30) beforeit has readthe END
command for a paramacroDO loop.
MISSING (F) IN INVERSE TIME AnF-word must beprogrammed inevery motionblock that isnot rapid whenin inversetime
feed mode (G93). F isnot modal inG93.
MISSING (GOTO) COMMAND An IFparamacro conditiondoes not havea GOTO witha sequencenumber following the
condition.
MISSING A (DO) COMMAND A WHILEparamacro conditiondoes not havea DOwith aloop identifier followingthe condition.
MISSING ADAPTIVE FEED DATA An attempt was made to create a transfer linepart program from the quick view screenwith
incomplete adaptive feedrate data.
MISSING COMMA An error occurred inG05 DH+communications block.
MISSING COMMA OR RIGHTPARENTHESIS An error occurredin G05DH+ communicationsblock.
MISSING CUTTER COMP CODE Cutter compensationmust be activatedbefore initiatinga G89irregular pocket cycle.
MISSING DATA FROM BLOCK G89 irregularpocket cycle parametersare missingfrom athe G89programming block.
MISSING END PARENTHESIS An error occurred inG05 DH+communications block.
MISSING G67 An active modal macro(G66 orG66.1) wasnot canceled bya G67before thecontrol readan
M02 or M30 end-of-program command.
MISSING HPG FROM I/ORING The I/Oassignment file that wascompiled anddownloaded withPAL defines an HPGthat is not
physically present inthe I/Oring. Verifythat the HPG address settingsare correct.
