Appendix
C
C-1
G-code Tables
This appendix lists the G-codes for 9/Series turning center. This table is
presented numerically by G--code system B along with a brief description
of their use. These G-codes are discussed in detail in the sections within
this manual that refer to their specific use.
The group numbers given in the table refer to modality. Group 00 is not
modal and independent of other G-codes. The remaining G-code groups
are modal with other G-codes with the same group number. This means
programming a G-code in group 1 replaces any other active group 1
G-code, but does not affect any G-codes that are not in group 1.
Important: This manual assumes that G--code system C is used.
Table 1.A
G-code Table
A B C Modal Function Type
G00 01 Rapid Positioning Modal
G01 LinearInterpolation
G02 CircularInterpolation (Clockwise)
G03 CircularInterpolation (Counterclockwise)
G04 00 Dwell Nonmodal
G05
0
0
Send Command and Wait for ReturnStatus
(used with 9/Series DataHighway PlusCommunication Module)
N
o
n
m
o
d
a
l
G05.1 -- G05.4 Send Commandand Wait for Return Status
(used with 9/Series DataHighway PlusCommunication Module)
G07 18 Programming UsingRadius Values Modal
G08 ProgrammingUsing Diameter Values
G09 00 Exact Stop Nonmodal
G10L2 Setup Work CoordinateOffset Table
N
o
n
m
o
d
a
l
G10L3 Setup Tool Management Table
G10L10 Setup Tool Offset Values GeometryTable
G10L11 Setup ToolOffset Values Wear Table
G10.1 Setup Random Tool Table
G10.2L1 Communication Configuration Table
(used with 9/Series DataHighway PlusCommunication Module)
G10.2L2 Output Command Table
(used with 9/Series DataHighway PlusCommunication Module)
G10.2L3 Download Configuration Information
(used with 9/Series DataHighway PlusCommunication Module)
G11 Setup ToolManagement Table (Cancel)
Appendix Overview
Interpreting G-codes
