Manual

G-codeTables
Appendix C
C-2
A TypeFunctionModalCB
G12.1 21 Spindle 1 Controlling Modal
G12.2 Spindle 2 Controlling
G12.3 Spindle 3 Controlling
G13 00 QuickPath Plus (UseFirst Intersect.) Nonmodal
G13
0
0
QuickPath Plus (Use SecondIntersect.)
N
o
n
m
o
d
a
l
G14 19 Scaling (Disable) Modal
G14.1 Scaling (Enable)
M
o
d
a
l
G15 15 Virtual C(Cancel)
G16.1 VirtualC CylindricalInterpolation
G16.2 VirtualC EndFace Milling
G17 02 Plane Selection
G18 PlaneSelection
G19 PlaneSelection
G90 G77 G20 01 Single PassO.D. and I.D. Roughing
G92 G78 G21 SinglePass ThreadCycle
G94 G79 G24 SinglePass RoughFacing Cycle
G22 04 Programmable Zone2 and3 (On)
G22.1 Programmable Zone 3 (On)
G23 ProgrammableZone 2 and 3 (Off)
G23.1 Programmable Zone (Off)
G27 00 Machine Home Return Check Nonmodal
G28 AutomaticReturn to Machine Home
G29 AutomaticReturn from Machine Home
G30 Returnto Secondary home
G31 ExternalSkip Function 1
G31.1 External SkipFunction 1
G31.2 External SkipFunction 2
G31.3 External SkipFunction 3
G31.4 External SkipFunction 4
G32 G33 G33 01 Constant Lead ThreadCutting Modal
G34 Variable Lead Thread Cutting
M
o
d
a
l
G36 22 Short Block Acc/Dec (Enable)
G36.1 Short Block Acc/Dec(Disable)
G37 00 Tool Gauging SkipFunction 1 Nonmodal
G37.1 Tool GaugingSkip Function1
G37.2 Tool GaugingSkip Function2
G37.3 Tool GaugingSkip Function3
G37.4 Tool GaugingSkip Function4
G39 20 Tool TipRadius Compensation(Linear Generated Block) Modal
G39.1 Tool Tip RadiusCompensation (Circular Generated Block)
M
o
d
a
l
G40 07 ToolTipRadius Compensation(Cancel)
G41 Tool TipRadius Compensation(Left)
G42 Tool TipRadius Compensation(Right)
