Manual

G-codeTables
Appendix C
C-4
A TypeFunctionModalCB
G75 G75 G77 O.D. andI.D. Grooving Cycle
G76 G76 G78 O.D. andI.D. Multi-Pass ThreadingRoutine
G80 09 Cancel or end fixed cycle Modal
G81 Drillingcycle (no dwell, rapid out)
G82 Drillingcycle (dwell, rapid out)
G83 Deephole peck drilling cycle
G83.1 Deep hole peck drillingcycle (dwell)
G84 Right handtapping cycle
G84.1 Left hand tapping cycle
G84.2 Right hand solid tapping cycle
G84.3 Left hand solid tapping cycle
G85 Boringcycle (no dwell, feed out)
G86 Boringcycle (spindle stop, rapid out)
G86.1 Boring cycle (spindle shift)
G87 Backboring cycle
G88 Boringcycle (spindle stop, manual out)
G89 Boringcycle (dwell, feed out)
---- G90 G90 03 Absolute mode
---- G91 G91 Incrementalmode
G50 G92 G92 00 Coordinate offset using toolpositions Nonmodal
G50 G92 G92 Maximum CSSSpindle RPM
G92.1 Coordinate system offset cancel
G92.2 Cancel select offsets
G98 G94 G94 05 Feed per minutemode Modal
G99 G95 G95 Feedper revolution mode
G96 17 CSS ON Modal
G97 RPMSpindle Speed Mode
---- G98 G98 10 Initial level returndrilling cycles Modal
---- G99 G99 R-point levelreturn drillingcycles
END OF APPENDIX
