Allen-Bradley 7300 Series CNC
Tape Compatibility
Appendix D
D-12
The main program, which has the pattern repeat call block “(CP, name, r),”
can be executed from tape or from the control memory. However, if you
want to make minor editing to your main program, you must copy the
program into the control memory. Refer to section 10.2, “Inputting Part
Programs,” for details on how to copy a program from tape.
Important: To execute a program from tape, the tape must be positioned
at the start of the main program.
For more information on how subprograms are executed in the control,
refer to chapter 10, “Subprogram Call (M98).”
You may enhance your 7300 part program flexibility with selected 9/Series
features. In addition to those 7300 G-codes described earlier, Table D.C
lists the 9/Series G-codes that are also available to be executed in 7300
mode. Refer to earlier sections of this manual for details on these G-codes.
Table D.C
9/Series Lathe G-codes Available in 7300 Mode
G-code: Description:
G09 Exact stop
G10L2 Set up workcoordinate offset table
G10L3 Set up tool management table
G10L10 Set up tooloffset geometrytable
G10L11 Set up tool offset wear table
G11 Set uptool management tablecancel
G14 Disable scaling
G20 Single passID & ODroughing
G24 Single passrough face
G27 Machine homereturn check
G30 Return tosecondary home
G31 External skip function1
G36 Short block Acc/Dec disabled
G37 Tool gauging skipfunction 1
G38 Hole probing
G39 TTRC (Linear Transition)
G52 Offset coordinate zero point
G53 Motion inmachine coordinatesystem
G54 Preset work coordinate system 1
9/Series G-codes Applicable
to the 7300 Series CNC
