SA3100 Local Tunable Variables
C-7
P1HZ_E3! Point 1 Frequency
This value is set to select the frequency at
point 1 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz
∗
1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
P2HZ_E3! Point 2 Frequency
This value is set to select the frequency at
point 2 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz
∗
1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
P3HZ_E3! Point 3 Frequency
This value is set to select the frequency at
point 3 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz
∗
1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
P4HZ_E3! Point 4 Frequency
This value is set to select the frequency at
point 4 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz
∗
1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
P5HZ_E3! Point 5 Frequency
This value is set to select the frequency at
point 5 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz
∗
1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
P6HZ_E3! Point 6 Frequency
This value is set to select the frequency at
point 6 in the V/Hz characteristic curve.
This value is entered in hertz times 1000, e.g.,
60 hertz is entered as 60000.
Units: Hz ∗ 1000
Default Value: 0
Low Limit: 0
High Limit: 660000
Step: 1
