3-22
SA3100 Drive Configuration and Programming
Drive Control Register (Continued) 100/1100
Bit 11
Reserved for future use.
Hex Value: 0800H
Sug. Var. Name:
Access: Read only
UDC Error Code: N/A
LED: N/A
Bit 12
Reserved for Future Use.
Hex Value: 1000H
Sug. Var. Name:
Access: Read only
UDC Error Code: N/A
LED: N/A
UDC Task Running Bit 15
The UDC Task Running bit is a status bit
that indicates that the UDC task is running.
This bit is used by the PMI Regulator to
prevent the minor loop from running if the
UDC task is not running.
Hex Value: 8000H
Sug. Var. Name: UDC_RUN@
Access: Read only
UDC Error Code: N/A
LED: N/A
This bit must NOT be written to by the user. This is a status bit that must only be
written to by the operating system.
I/O Control Register 101/1101
The I/O Control Register contains the bits that control the EXT FLT LED on the PMI, the Auxiliary Output on
the Resolver & Drive I/O board, and the operation of the resolver external strobe input.
No Slip Adjustment (Vector with Constant Power) Bit 0
The No Slip Adjustment command bit is set
during constant power drive commissioning.
Setting this bit causes the drive to disable
slip accommodation.
Hex Value: 0001H
Sug. Var. Name: NO_ADJ@@
Access: Read/Write
UDC Error Code: N/A
LED: N/A
No Slip Smoothing (Vector with Constant Power) Bit 1
The No Slip Smoothing command bit is set
during constant power drive commissioning.
Setting this bit causes the drive to disable
magnetizing current interpolation.
Hex Value: 0002H
Sug. Var. Name: NO_INTR@
Access: Read/Write
UDC Error Code: N/A
LED: N/A
