SA3100 Drive Configuration and Programming
Interlock Register (Continued) 205/1205
MCR Did Not Close Bit 7
The MCR Did Not Close bit is set if the
optional output contactor did not close when
commanded to do so.
Hex Value: 0080H
Sug. Var. Name: IC_MCR@
Access: Read only
UDC Error Code: N/A
LED: N/A
Bit 8
Reserved for future use.
Hex Value: 0100H
Sug. Var. Name:
Access: Read only
UDC Error Code: N/A
LED: N/A
Bit 9
Reserved for future use.
.
Hex Value: 0200H
Sug. Var. Name:
Access: Read only
UDC Error Code: N/A
LED: N/A
Incompatible Resolver Bit 10
The Incompatible Resolver bit is set if
Resolver & Drive I/O boards B/M 60001 or
B/M 60001-1 are detected in the PMI
Regulator.
Hex Value: 0400H
Sug. Var. Name: IC_IRES@
Access: Read only
UDC Error Code: N/A
LED: N/A
DC Bus Voltage (Volts) Register 206/1206
The DC Bus Voltage (Volts) register contains the voltage of the DC
bus. It is scaled in units of volts.
Sug. Var. Name: BUS_VDC%
Units: Volts
Range: N/A
Access: Read only
DC Bus Current (Amps) Register 207/1207
The DC Bus Current (Amps) register contains the measured current
in the DC bus. The value is scaled in amps times 10. For example,
50.1 amps would be represented as 501.
Sug. Var. Name: BUS_IDC%
Units: Amps ∗ 10
Range: N/A
Access: Read only
