SA3100 Drive Configuration and Programming
UDC Test Switch Inputs Register (Continued) 1000
COMM A OK LED Bit 9
The COMM A OK LED bit shows the status
of the COMM A OK LED on the UDC
module ( 0 = OFF; 1 = ON).
Hex Value: 0200H
Sug. Var. Name: N/A
Access: Read only
UDC Error Code: N/A
LED: COMM A OK
on UDC module
Drive A Fault LED Bit 10
The Drive A Fault LED bit shows the status
of the Drive A Fault LED on the UDC
module ( 0 = OFF; 1 = ON).
Hex Value: 0400H
Sug. Var. Name: N/A
Access: Read only
UDC Error Code: N/A
LED: DRV A FLT
on UDC module
COMM B OK LED Bit 11
The COMM B OK LED bit shows the status
of the COMM B OK LED on the UDC
module ( 0 = OFF; 1 = ON).
Hex Value: 0800H
Sug. Var. Name: N/A
Access: Read only
UDC Error Code: N/A
LED: COMM B OK
on UDC module
Drive B Fault LED Bit 12
The Drive B Fault LED bit shows the status
of the Drive B Fault LED on the UDC
module ( 0 = OFF; 1 = ON).
Hex Value: 1000H
Sug. Var. Name: N/A
Access: Read only
UDC Error Code: N/A
LED: DRV B FLT
on UDC module
