Owner’s Manual Manual del usuario Manual do proprietário Gebruikershandleiding Deutsch Français Italiano Manuale dell'utente Español Mode d'emploi Português Bedienungsanleitung Nederlands Owner’s Manual English Guitar Amplifier
WARNING: To reduce the risk of fire or electric shock, do not expose this apparatus to rain or moisture. RISK OF ELECTRIC SHOCK DO NOT OPEN The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons. CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK).
Owner’s Manual Switchable between two channels: CLEAN and LEAD (p. 4) • Simply press a single button to switch between the CLEAN and LEAD channels. • The LEAD channel provides four different distortion sounds: OVERDRIVE, DISTORTION, METAL ZONE, and EXTREME. Power Squeezer function (p. 4) • This allows you to obtain a good tonal balance even at low volume, letting you enjoy powerful sound even when you’re at home. Deutsch • Ideal for practicing at home.
USING THE UNIT SAFELY About WARNING and CAUTION Notices Used for instructions intended to alert the user to the risk of death or severe injury should the unit be used improperly. Used for instructions intended to alert the user to the risk of injury or material damage should the unit be used improperly. * Material damage refers to damage or other adverse effects caused with respect to the home and all its furnishings, as well to domestic animals or pets.
IMPORTANT NOTES • Do not connect this unit to same electrical outlet that is being used by an electrical appliance that is controlled by an inverter (such as a refrigerator, washing machine, microwave oven, or air conditioner), or that contains a motor. Depending on the way in which the electrical appliance is used, power supply noise may cause this unit to malfunction or may produce audible noise.
Panel Descriptions Control Panel 1 1. 7 8 3 2 [SELECT] Switch Switches between the CLEAN and LEAD channels. You can confirm which channel is selected by checking the indicator’s color (CLEAN: green; LEAD: red). CLEAN Channel 3. [VOLUME] Knob LEAD Channel Type Switch Type Description OVERDRIVE Natural distortion sound similar to that obtained by turning an amp’s volume up completely. DISTORTION Harder distortion than OVERDRIVE.
Connections Refer to the figure shown below to connect the CUBE-15XL to other equipment. * To prevent malfunction and/or damage to speakers or other devices, always turn down the volume, and turn off the power on all devices before making any connections. CD Player Digital Audio Player etc. Recorder Headphones * Before making the connections, be sure that the volume setting of the [VOLUME] knob for both amplifiers is set to 0.
Specifications CUBE-15XL Rated Power Output Nominal Input Level Speakers 15 W INPUT (CLEAN channel) -10dBu/1MΩ AUX IN -10dBu 20 cm (8 inch) [POWER] Switch [SELECT] Switch [POWER SQUEEZER] Switch Controls [VOLUME] Knob TYPE Switch (OVERDRIVE, DISTORTION, METAL ZONE, EXTREME), [GAIN] Knob, [VOLUME] Knob [BASS] Knob, [MIDDLE] Knob, [TREBLE] Knob Indicators CLEAN Channel, LEAD Channel Connectors INPUT Jack, AUX IN Jack, RECORDING OUT/PHONES Jack Power
Information AFRICA EGYPT Al Fanny Trading Office 9, EBN Hagar Al Askalany Street, ARD E1 Golf, Heliopolis, Cairo 11341, EGYPT TEL: (022)-417-1828 REUNION MARCEL FO-YAM Sarl 25 Rue Jules Hermann, Chaudron - BP79 97 491 Ste Clotilde Cedex, REUNION ISLAND TEL: (0262) 218-429 SOUTH AFRICA T.O.M.S. Sound & Music (Pty)Ltd. 2 ASTRON ROAD DENVER JOHANNESBURG ZA 2195, SOUTH AFRICA TEL: (011) 417 3400 Paul Bothner(PTY)Ltd.
For China For EU Countries
For EU Countries This product complies with the requirements of EMCD 2004/108/EC and LVD 2006/95/EC. For C.A. US (Proposition 65) WARNING This product contains chemicals known to cause cancer, birth defects and other reproductive harm, including lead.
