18 MB770 User’s Manual
J8: GDVP (DVI) Port Connector
Signal Name Pin # Pin # Signal Name
+5V 1 2 +5V
+5V 3 4 +5V
+3.3V 5 6 +3.3V
+1.5V 7 8 +1.5V
SMB_DA 9 10 SMB_CK
HS 11 12 VS
D0 13 14 DE
D2 15 16 D1
D4 17 18 D3
GND 19 20 D5
CLK 21 22 GND
CLK_N 23 24 GND
D7 25 26 D5
D9 27 28 D8
D11 29 30 D10
J9: LCD Inverter Output
Pin # Signal Name
1 +12V
2 Ground
3 BLT_ON
4 NC
5 Vcc
J11, J12: LVDS Connectors (1st channel, 2nd channel)
The LVDS connectors on board consist of the first channel (J11) and
second channel (J12) and supports single or dual channel 18-bit or
24-bit.
Signal Name Pin # Pin # Signal Name
TX0- 2 1 TX0+
Ground 4 3 Ground
TX1- 6 5 TX1+
5V/3.3V 8 7 Ground
TX3- 10 9 TX3+
TX2- 12 11 TX2+
Ground 14 13 Ground
TXC- 16 15 TXC+
5V/3.3V 18 17 ENABKL
+12V 20 19 +12V
