Integrated Peripherals
This section sets configurations for your hard disk and other integrated
peripherals.
Phoenix - Award WorkstationBIOS CMOS Setup Utility
Integrated Peripherals
VIA OnChip IDE Device
Press Enter ITEM HELP
VIA OnChip PCI Device
Press Enter Menu Level
SuperIO Device
Press Enter
2nd SuperIO Device
Press Enter
Onboard Serial Port 3
3E8h
Serial Port 3 Use IRQ
IRQ11
Onboard Serial Port 4
2E8h
Serial Port 4 Use IRQ
IRQ10
VIA OnChip IDE Device
Upon pressing Enter on this field, another window appears. Below are
the fields shown with their respective default settings:
OnChip SATA – Enabled
SATA Mode – IDE
OnChip IDE Channel0 – Enabled
OnChip IDE Channel1 – Enabled
IDE Prefetch Mode – Enabled
Primary Master PIO – Auto
Primary Slave PIO – Auto
Secondary Master PIO – Auto
Secondary Slave PIO – Auto
Primary Master UDMA – Auto
Primary Slave UDMA – Auto
Secondary Master UDMA – Auto
Secondary Slave UDMA – Auto
IDE HDD Block Mode – Enabled
VIA OnChip PCI Device
Upon pressing Enter on this field, another window appears. Below are
the fields shown with their respective default settings:
VIA-3058 AC97 Audio – Auto
VIA-3043 OnChip LAN – Enabled
Onboard LAN Boot ROM – Disabled
OnChip USB Controller – Enabled
OnChip EHCI Controller – Enabled
USB Emulation – OFF
USB Keyboard Support – Disabled
USB Mouse Support – Disabled
[
