User`s manual

INTRODUCTION
MB770 User’s Manual 1
Introduction
Product Description
The MB770 Mini ITX board incorporates the VIA CN700 chipset.
Currently, the board is available in two models, namely:
1. MB770 - VIA Eden-V4 400MHz, CN700 chipset, Mini-ITX w/
10/100 LAN, VGA, Mini PCI, SATA
2. MB770F - VIA Eden-V4 1GHz, CN700 chipset, Mini-ITX w/ 10/100
LAN, Gigabit LAN, VGA, Mini PCI, SATA, TV out
Optional for the MB770/MB770F is the ID393 daughter card that
supports DVI interface.
Basically, the MB770 has the following features:
• VIA CN700 Chipset with VIA CPU
• Up to 1GHz speed and 1GB DDR2 memory
• Integrated VGA, support 18/24-bit LVDS LCD
• 10/100 LAN1 on board, optional Gigabit LAN for LAN2
• 6 x USB, 2 x SATA ports
• 4 COM ports, Watchdog timer
• PCI and Mini PCI slots on board, optional TV out
Remarks: The onboard PCI slot supports 2 masters.
