User`s manual

BIOS SETUP
48 MB770 User’s Manual
PC Health Status
Phoenix - Award WorkstationBIOS CMOS Setup Utility
PC Health Status
ITEM HELP
Thermal Duty Cycle
Disabled
CPU Warning Temperature
Disabled
System Temp.
39°C/102°F
CPU Temp.
32°C/89°F
CPU FAN Speed
0 RPM
System FAN Speed
0 RPM
Vcore
1.63V
3.3V
3.37V
+5V
5.05V
+12V
12.09V
-12V
-12.03V
-5V
- 4.79V
VBAT(V)
3.21V
5VSB(V)
5.05V
Shutdown Temperature
Disabled
Thermal Duty Cycle
By default, this field is disabled.
CPU Warning Temperature
This field allows the user to set the temperature so that when the
temperature is reached, the system sounds a warning. This function can
help prevent damage to the system that is caused by overheating.
Temperatures/Fan Speeds/Voltages
These fields are the parameters of the hardware monitoring function
feature of the motherboard. The values are read-only values as
monitored by the system and show the PC health status.
Shutdown Temperature
This field allows the user to set the temperature by which the system
automatically shuts down once the threshold temperature is reached.
This function can help prevent damage to the system that is caused by
overheating.
