5.
Features Full-duplex playback and recording. Built-in 16-bit CODEC Support Microsoft® DirectSound™. Also support earphones, 2/4/6 channel speaker mode DLS-based wavetable music Synthesizer, supports DirectMusic® PCI Rev. 2.2 compliant with bus mastering modes ACPI compliant power down management Support Windows® 2000, XP/2003/Vista/7/8 (32/64 bit) System Requirements Pentium-class computer with one available PCI slot Windows® 2000, XP/2003/Vista/7/8 (32/64 bit) DirectX 8.
Hardware Installation It is recommended that you remove any previously installed sound card and drivers prior to installing this 5.1 Channel PCI Sound Card to avoid any conflicts. If previously installed drivers are not removed, this 5.1 Channel PCI Sound Card perhaps not function properly. (Note: If your computer has on-board sound you will need to disable it on the motherboard. For more information please see your computer’s documentation or contact your computer’s manufacturer.
Physical Connections The rear panel of this 5.1 Channel PCI Sound Card has the following jacks: 1. Line In (blue) – Connect to tape/CD/DVD player, or other audio sources for output mixing and/or recording 2. Mic In (pink) – Connect to microphone 3. Front-Speaker (green) – Output to speakers with amplifier or earphones or audio-in of home stereo 4. Rear-Speaker (black) – Connect to the rear speakers while four/six channel speakers mode is enabled 5.
This 5.1 Channel PCI Sound Card also has the following internal connection and jumpers: The Function J1 Analog CD/IN Port(Signals: L-G-G-R) J2 Analog CD/IN Port(Signals: G-R-G-L) J3 Aux-in 1-2 close Center/Bass channel in normal mode 2-3 close Center/Bass channel in inverse mode JP1&JP2 Thank you for purchasing a quality Rosewill Product. Please register your product at : www.rosewill.com for complete warranty information and future support for your product.
