Installation Instructions & Warranty Commercial Style Pullout Spray Kitchen Faucet
® RVF1216CH Commercial Style Pullout Spray Kitchen Faucet Features • • • • • • Polished chrome finish Kerox™ Ceramic Disc Cartridge Solid brass construction Pull-out spray head with multi-function feature Up to 2” deck thickness 1 hole installation(standard 1-3/8” hole) Certified and listed by cUPC to meet Industry Codes and Standards for USA & Canada This product complies with the new federal “leadfree” requirement of the 2014 Reduction of Lead in Drinking Water Act, as well as state legislations in Cal
® RVF1216CH Tools Needed Groove point pliers Safety Tips Adjustable wrench Phillips head screwdriver WARNING • Ruvati reccomends that this product only be installed by a licensed professional. • Always shut off the water supply befor removing the existing faucet and/ or installing a new one. Open the hot and cold knobs on the existing faucet in order to release built up pressure. • Always wear saftely glasses when cutting or soldering water supply lines • Keep the drain covered to avoid losing parts.
® RVF1216CH In the Box Faucet Body Rubber Gasket A Rubber Gasket B Rubber Washer Metal Washer Faucet Head Locknut Threaded Shank Hot & Cold Hose Pipes Spray Hose Pipe Spray Hose Weight Spray Hose Hot & Cold Water Supply Hoses ® www.ruvati.
® RVF1216CH Installation 1. Remove rubber washer, metal washer, and locknut from the threaded shank (Figure 1). Figure 1 2. Place the faucet body into the faucet hole of the deck/sink (Figure 2). A standard 1-3/8” hole is required for this faucet. Figure 2 3. From underneath the deck/sink, slide the rubber washer followed by the metal washer all the way up the threaded shank of the faucet (Figure 3). 4. Screw the locknut all the way up the threaded shank of the faucet until tight.
® RVF1216CH 5. Unscrew both screws of the hose weight until it is in two pieces. Place one half of the hose weight on the center sections of the spray hose. Then place the remaining half of the weight against the other half and reinsert the screws. Do not tighten the screws completely yet (Figure 4). Figure 4 6. Place rubber gasket A into the female end of the spray hose pipe (the longest copper pipe extending from the faucet’s base).
® RVF1216CH 9. Then screw the remaining female ends of the supply hoses to the corresponding hot and cold water supply valves using an adjustable wrench or pliers (Figure 7). Figure 7 10. Turn water supply on (Figure 8). Turn the faucet on to let water run through it and flush out any dirt / debris. Turn faucet off now. Figure 8 11. Insert rubber gasket B into the end of the top end of the faucet. Then attach the faucet head by screwing until tight (Figure 9). Test the faucet by turning it on and off.
® RVF1216CH [BLANK PAGE] ® www.ruvati.
® RVF1216CH Trouble-Shooting Guide Issue Cause The water will not completely turn off. There is a dirty, worn out, or damaged washer in the cartridge. Check to see if the ceramic disc is dirty or damaged by removing the handle and the cartridge. Water is leaking from under the handle. The adjusting ring or cap has become loose. Tighten the adjusting ring or cap. The aerator is leaking or has an inconsistent water flow pattern. The aerator does not fit correctly or has become dirty.
® RVF1216CH RUVATI LIMITED LIFETIME WARRANTY At RUVATI, we stand behind our products with a limited lifetime warranty on all faucets. We want every RUVATI customer to be a satisfied customer. REGISTER YOUR PRODUCT. By taking just a few minutes to register, you can improve your experience with Ruvati and enjoy more efficient Warranty Support. Visit www.ruvati.
® RVF1216CH This warranty gives customer specific legal rights, and customer may also have other rights which vary from state to state. When requesting warranty service, you will need to provide: 1. an approved Return Merchandise Authorization number (RMA) issued by Customer Service 2. a dated, valid proof of purchase (payment receipt from an authorized Ruvati reseller) 3.
RVF1216CH REGISTER YOUR PRODUCT. By taking just a few minutes to register, you can improve your experience with Ruvati and enjoy more efficient Warranty Support. Visit www.ruvati.com Tel. (855)478-8284 ® www.ruvati.com Fax (855)239-8053 email: support@ruvati.com www.ruvati.
