Installation Instructions & Warranty Commercial Style Pullout Spray Kitchen Faucet
® RVF1218ST Commercial Style Pullout Spray Kitchen Faucet Features • • • • • • Stainless steel finish Kerox™ Ceramic Disc Cartridge Solid brass construction Pull-out spray head with multi-function feature Up to 2” deck thickness 1 hole installation(standard 1-3/8” hole) Certified and listed by cUPC to meet Industry Codes and Standards for USA & Canada This product complies with the new federal “leadfree” requirement of the 2014 Reduction of Lead in Drinking Water Act, as well as state legislations in Cal
® RVF1218ST Tools Needed Groove point pliers Safety Tips Adjustable wrench Phillips head screwdriver WARNING • Ruvati reccomends that this product only be installed by a licensed professional. • Always shut off the water supply befor removing the existing faucet and/ or installing a new one. Open the hot and cold knobs on the existing faucet in order to release built up pressure. • Always wear saftely glasses when cutting or soldering water supply lines • Keep the drain covered to avoid losing parts.
® RVF1218ST In the Box Faucet Body Rubber Gasket Rubber Washer Metal Washer Locknut Threaded Shank Hot & Cold Hose Pipes Spray Hose Pipe Spray Hose Hot & Cold Water Supply Hoses ® www.ruvati.
® RVF1218ST Installation 1. Remove rubber washer, metal washer, and locknut from the threaded shank (Figure 1). Figure 1 2. Place the faucet body into the faucet hole of the deck/sink (Figure 2). A standard 1-3/8” hole is required for this faucet. Figure 2 3. From underneath the deck/sink, slide the rubber washer followed by the metal washer all the way up the threaed shank of the faucet (Figure 3). 4. Screw the locknut all the way up the threaded shank of the faucet until tight.
® RVF1218ST 6. Place rubber gasket into the female end of the spray hose pipe (longest copper pipe extending from the faucet’s base) and connect the flexible spray hose by screwing it in and tightening with an adjustable wrench.(Figure 4). Figure 4 7. Attach the hot and cold water supply hoses to the faucet by screwing the male end of each hose with an adjustable wrench or pliers to each of the copper supply hose pipes extending from the base of the faucet (Figure 5). Figure 5 ® www.ruvati.
RVF1218ST ® 8. Then screw the remaining female ends of the supply hoses to the corresponding hot and cold water supply valves using an adjustable wrench or pliers (Figure 6). Figure 6 10. Turn water supply back on (Figure 7). Test the faucet by turning faucet on and off. Make sure there is good water flow and no leaks. If there is a leak, turn the water supply off and contact Ruvati. Figure 7 ® www.ruvati.
® RVF1218ST [BLANK PAGE] ® www.ruvati.
® RVF1218ST Trouble-Shooting Guide Issue Cause The water will not completely turn off. There is a dirty, worn out, or damaged washer in the cartridge. Check to see if the ceramic disc is dirty or damaged by removing the handle and the cartridge. Water is leaking from under the handle. The adjusting ring or cap has become loose. Tighten the adjusting ring or cap. The aerator is leaking or has an inconsistent water flow pattern. The aerator does not fit correctly or has become dirty.
RVF1218ST ® RUVATI LIMITED LIFETIME WARRANTY At RUVATI, we stand behind our products with a limited lifetime warranty on all faucets. We want every RUVATI customer to be a satisfied customer. REGISTER YOUR PRODUCT. By taking just a few minutes to register, you can improve your experience with Ruvati and enjoy more efficient Warranty Support. Visit www.ruvati.
RVF1218ST This warranty gives customer specific legal rights, and customer may also have other rights which vary from state to state. When requesting warranty service, you will need to provide: 1. an approved Return Merchandise Authorization number (RMA) issued by Customer Service 2. a dated, valid proof of purchase (payment receipt from an authorized Ruvati reseller) 3.
