Replacement Part List

3
P2606/P2606VNM
PARTS LIST
KEY NO. PART NO. DESCRIPTION QTY.
14 670914001 Washer (M6, OD11 x ID6.2 x 0.3t) 3
15 610114001 Center Gear 1
16 670704001 Retaining Ring 1
17 660137001 Screw w/Tooth Washer (M4 x 12 mm, Pan Hd.) 2
18 311826001 Blade Assembly 1
19
941588102 Data Label (P2606) 1
941588558 Data Label (P2606VNM) 1
20 660208052 Screw (M4 x 16 mm, Pan Hd.) 4
21 526799004 Hedge Sweep 1
22 525406005 Blade Shield 1
23 940851647 Rotating Handle Label 1
24 940705490 Logo Label 2
Not Shown:
991000689 Operator’s Manual
KEY NO. PART NO. DESCRIPTION QTY.
1 661817001 Screw (M4 x 14 mm, T15 Torx Pan Hd.) 13
2 311825001 Handle Assembly 1
3 311829001 Trigger Assembly 1
4 679055007 Compression Spring 1
5 679055008 Compression Spring 2
6 311827001 Wiring Harness 1
7 941769001 Warning Icon Label 1
8 660137010 Screw w/Washers (M4 x 26 mm, T15 Torx Pan Hd.) 2
9
311824001 Housing Assembly (Inc. Key Nos. 19, 23-24) (P2606) 1
317346001 Housing Assembly (Inc. Key Nos. 19, 23-24) (P2606VNM) 1
10 317345001 Top Cover Assembly (Inc. Key No. 7) 1
11 529546001 Front Handle 1
12 311828001 Motor and Pinion Assembly 1
13 307878001 Gear Box w/Cover Assembly 1
