Replacement Part List

RYOBI 40V LAWN MOWER − MODEL NO. RY40LM01
3
PARTS LIST
39 613728001 Handle Height
Adjustment Disc (Right) .........................1
40 613727001 Handle Height
Adjustment Disc (Left) ........................... 1
41 536916001 Side Handle Latch ................................. 2
42 205223001 Front Handle Latch Assembly ............... 1
43 205224001 Bag Hanger (Inc. Key Nos. 62 & 81) ......1
44 536919001 Side Compression Disc Holder .............2
45 697483001 Handle Compression Spring .................2
46 565024001 Rubber Compression Disc ....................2
47 639120001 Motor Axle Bushing ...............................1
48 536915001 Handle Latch (Right Front) ....................1
49 635985001 Wiring Strap (20 mm) ............................2
50 660925003 Screw (M4 x 12 mm, T20 Torx Hd.) .....12
51 635790001 Wiring Hold Down Plate (10 mm) ..........4
52 678889003 Washer (ID12.5 x OD24 x 2t) ................. 2
53 690689001 Rotor Nut ...............................................2
54 537693001 Push Button ..........................................2
55 565215001 Foam Pad .............................................. 2
56 313618001 8 in. Wheel Assembly
(Inc. Key No. 64) .................................... 2
57 941641001 CPSC Cut Finger Label ......................... 1
58 941851160 Onboard Battery Storage Label ............1
59 941851158 Main Danger Label (EN/FR) ...................1
60 313619001 10 in. Wheel Assembly
(Inc. Key No. 64) .................................... 2
61 941851128 Start Key Hangtag ................................. 1
62 941851130 Attachment User Callout Label .............1
63 941851133 Handle Lockout Label ...........................1
64 535063001 Wheel Hub .............................................4
65 903718001 21 in. Grass Bag ....................................1
66 941851124 Front Logo Label ...................................1
67 941851125 Handle Logo Label ................................ 1
68 941851127 Start Key Warning/Data Combo Label .. 1
69 205193001 21 in. Deck Assembly
(Inc. Key Nos. 17 & 57) .......................... 1
70 205195001 Front Bumper Cover Assembly
(Inc. Key No. 66) .................................... 1
71 635490001 Front Axle ..............................................1
72 664004001 Screw (1/4-20 x 3/4 in.) .......................10
73 635512001 Front Axle Mount ................................... 2
74 681957001 Ball Bearing (ID12 x OD32 x 10 mm).....8
75 613958001 Wheel Bushing ......................................4
76 535046001 Wheel Cover .......................................... 2
1 205216001 Upper Handle Assembly
(Inc. Key No. 19) .................................... 1
2 205217001 Trigger Assembly ...................................1
 3 280749001 玽DriveMotorController ........................... 1
4 280747001 Blade Circuit Board Controller ..............1
5 760961002 Momentary Switch ................................1
6 760551003 Switch (Red) ..........................................2
7 696926001 Spring .................................................... 2
8 661189003 Screw (M4.0 x 18 mm,
T15 Torx Pan Hd.) ................................ 46
9 696931001 Guide Tube ............................................ 2
10 205214001 Blade Button Trigger Assembly .............1
11 205212001 Upper Handle Housing
(Inc. Key No.63) ..................................... 1
12 205218001 Deck Height Adjustment Housing
(Inc. Key Nos. 83-84) .............................1
13 205219001 Battery Housing Vent Assembly ............1
14 T205220001 Transmission Mount &
Spacer Assembly ..................................1
15 697111001 Compression Spring .............................2
16 314359001 Speed Sensor Switch Assembly ........... 1
17 940851498 Deck Size Label.....................................1
18 941851159 Main Danger Label (SP).........................1
19 941851177 Starting Instructions Label ....................1
20 941851178 Handles Fully Extended Label ...............1
21 918016031 Mulch Plug Hangtag ..............................1
22 205221001 Slide Bushing Assembly ........................1
23 205222001 Rear Handle Latch Assembly ................ 1
24 205190001 Structural Frame Assembly
(Inc. Key Nos. 20 & 67) .......................... 1
25 534997001 Telescoping Latch ................................. 2
26 535214001 Telescopic Bushing ............................... 2
27 635484001 Tube (Right) ...........................................1
28 635360001 Tube (Left) ..............................................1
29 760551002 Switch (Black) ........................................1
30 535054001 Fix Bushing Switch ...............................1
31 635516001 Handle Cover ........................................2
32 660527001 Screw (M5 x 14, T25 Torx Soc. Hd.) ....10
33 635532001 Lower Handle (Left) ...............................1
34 205191001 Lower Handle (Right, Inc. Key No. 80) ...1
35 535017001 Handle Cam Lever.................................2
36 673824001 Cam Pin .................................................2
37 673874001 Cam Lever Dowel (4 mm) ...................... 2
38 696920001 Compression Spring .............................2
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label attached to the deck. Always mention the model number in all
correspondence regarding your LAWN MOWER or when ordering replacement parts.
