Replacement Part List

RYOBI 40V LAWN MOWER − MODEL NO. RY40LM01
4
PARTS LIST
118 678460002 Lock Nut (M6) ....................................... 6
119 635496001 Height Adjustment Linkage ................... 1
120 661431003 Bolt (M6 x 14 mm, Hex Soc. Hd.) .........6
121 697164001 Height Adjustment Trigger Spring ......... 1
122 660353001 Bolt (M6 x 22 mm, Hex Hd.) .................. 1
123 637087001 E-Ring (ID 6 mm) ................................... 2
124 662082001 Flange Lock Nut .................................... 4
125 662065001 Screw (#5 unc x 1/2 in., Hex Hd.)..........2
126 890043001 Grass Catcher Sensor Switch ............... 1
127 660203001 Screw (M3 x 8 mm, Button Hd.) .......... 10
128 635333001 C-Ring (OD 10 mm) ............................... 2
129 660697002 Screw (M6 x 20 mm, T27 Torx Hd.) .......6
130 537792001 Spring Cover .........................................1
131 678002002 Al Rivet ..................................................2
132 678125001 Washer (OD12 x ID4.3 x 1t) ................... 1
133 696138001 Rivet ......................................................1
134 205187001 Top Battery Housing Cover
(Inc. Key Nos 18, 58, 61 & 68) ............... 1
135 660722002 Bolt (M6 x 26 mm) ................................. 4
136 742461001 40V-DC Motor .......................................1
137 205198001 Key Assembly (Inc. Key No. 61) .............1
138 639491001 Common Foot Contact Plate ................3
139 535272001 40V Foot ................................................ 2
140 532760002 Common Foot Cover .............................2
141 526912001 Key Connector Base .............................1
142 660608001 Brake Band Screw ................................2
143 639178001 Female Terminal .................................... 2
144 535005001 Battery Housing (Bottom) ......................1
145 205194001 Plug Cover Battery Housing (Front) ......1
146 696934001 Battery Clear Cover Spring ...................1
147 622330001 Pin .........................................................1
148 679073001 Battery Door Press Spring ....................1
149 535081001 LED Clear Window Lens .......................1
150 535082001 LED Reflection Cup ............................... 1
151 280738001 LED Circuit Board Assembly ................. 1
152 660230011 Screw (M3 x 10 mm, T10 Torx Hd.) .......4
153 635510001 Bag Frame .............................................1
NOT SHOWN:
995000685 Operator’s Manual
5-14-19
(Rev:01)
77 535047001 Baffle .....................................................1
78 T662406001 Square Nut (M8 x 1.25) .........................3
79 205199001 Mulching Plug Assembly
(Inc. Key No. 21) .................................... 1
80 941851117 Handle Instructions Label .....................1
81 941851119 Guard Warnings Label ........................... 1
82 941851120 Logo Label (Front) .................................1
83 941851122 Single Point Adjust Label ......................1
84 941851123 Cut Height Label ...................................1
85 679075001 Hex Nut (M10) .......................................1
86 535080001 Motor Fan Blade Adapter ......................1
87 291975001 Inner Wire w/Terminal ............................1
88 313626002 Battery Cover Assembly........................1
89 513211001 Cord Clip ...............................................6
90 660608002 Screw (M4 x 16 mm, T20 Torx Hd.) .....12
91 660970001 Screw (M4 x 17 mm, T20 Torx Hd.) .......5
92 280751001 Signal Conversion Interface Board .......1
93 635488001 Handle Bracket (Right) ..........................1
94 635487001 Handle Bracket (Left).............................1
95 635491002 Pedal Linkage ........................................1
96 696930001 Extension Spring ...................................2
97 660345009 Screw (M4 x 10 mm, T20 Torx Hd.) .......1
98 535181001 Handle Latch Pedal ............................... 1
99 635489001 Rear Axle w/Height Adjustment Plate ... 1
100 662160001 Screw (M8 x 16 mm, T40 Hex Hd.) .....13
101 291976001 Main Wiring Harness (Right) .................. 1
102 291977001 Main Wiring Harness ............................. 1
103 535014001 Motor Mount .........................................1
104 210449001 Transmission .........................................1
105 613239001 Drive Gear .............................................2
106 622068001 Gear Shaft .............................................2
107 690698001 Snap Ring ..............................................4
108 613738001 Drive Axle Bearing Sleeve .....................2
109 682164001 Ball Bearing ........................................... 2
110 535061001 Rear Guard ............................................ 1
111 673179002 Rivet ......................................................5
112 639118001 Blade Retainer .......................................1
113 682282001 21 in. Blade ...........................................1
114 660024061 Screw (M4 x 14 mm, T20 Torx Hd.) .......6
115 638557001 Washer (OD15 x ID6.2 x 0.8t) ................ 4
116 635495001 Height Adjustment Hook ....................... 1
117 696924001 Extension Spring ...................................1
KEY PART
NO. NUMBER DESCRIPTION QTY
KEY PART
NO. NUMBER DESCRIPTION QTY
The model number will be found on a label attached to the deck. Always mention the model number in all
correspondence regarding your LAWN MOWER or when ordering replacement parts.
