1 IN A FEW WORDS ... Switch on Press Press . Press Dial the number then press Answer Make a call from a number stored in the directory press , scroll down the list to find your correspondent, then press to call. By location in the directory: enter the location number then press to call. . * Switch off Press . twice. By name: enter the first letter of the name, . Hang up Press * then OK. Redial last number Call Press Lock and unlock the keyboard from the standby screen (long press).
2 MENUS Enter using Validate using OK Quit or return to the previous menu using C or Navigate using and Services Directory Games Accessories Text messages Security Call services Briefly, the menus Ringing and beeps ✄ Controls
You have just bought a mobile phone and we congratulate you on your choice. Your phone will allow you to use different international networks depending on the roaming agreements between the operators. We would like to remind you that this phone is approved to European standards. To get the most out of using your phone, we recommend that you read this manual carefully and keep it handy for future reference if needed.
1. Presentation of the phone ..................................... 6 1.1 Exchanging the coloured front panel ................... 9 2. Getting started ..................................................... 10 2.1 2.2 2.3 2.4 2.5 2.6 Information on the SIM card .............................. 10 Installing the SIM card and the battery .............. 11 Charging the battery ......................................... 12 Switching on/switching off, starting up .............. 13 Menu access ......................
9. How to adjust and customize your phone ............ 37 9.1 9.2 9.3 9.4 9.5 9.6 9.7 Customizing your phone ................................... 37 Selecting the display language ......................... 39 Select the type of response .............................. 39 Selecting the network ....................................... 39 Setting the time and date .................................. 40 Controlling screen contrast ............................... 40 Converting currencies ...........................
6 Antenna Indicator light Ear phone/speaker High definition graphics screen Programmable key 1 Correction Stop/End call Scrolling arrow Microphone WARNING! During a call, mind you do not obstruct the microphone with your hand. 1.
Function keys Stop Reject a call Hang up Go Call a number Receive a call Hands-free mode C Short press: Return to the previous menu Delete a character Long press: Exit menu mode Complete deletion of the entry OK Validate - Programmable keys for direct access to the functions that you have selected (depending on model) - Volume control during conversation key: louder) ( key: lower, - Contextual action @ Mobile Internet access key and Entry and scrolling through the menus.
8 Display The high definition graphics screen enables you to read messages easily. Various icons inform you about the status of functions. Battery charge indicator (black if charged, clear if discharged) Received signal strength indicator (maximum strength: 5 bars) ; the R letter indicates if the network found does not correspond to the subscription If flashes, the phone is searching for a network Hands-free loudspeaker Call in progress Permanent call forwarding Silent mode 1.
9 1.1 Exchanging the coloured front panel Release the front panel by moving the retention lugs (❷) if necessary and pushing them with a pen for example. Switch off the phone. Remove the rear cover and the battery (see on page 11). Hold the phone with the front panel facing downward, and with the antenna pressed against you. Free the front panel by moving the retention lugs (➊). 1 1 1 2 2 1 Install the keyboard in the new front panel. Position the phone and the new front panel as shown.
10 2.1 Information on the SIM card To use your phone, you have a small card called a SIM card. In addition to all of the information necessary for the network, this card contains other information that you can modify: 2. Getting started 2. Getting started secret codes (PIN and PIN2 Personal Identification Number) directory mini-messages functioning of specific services.
PIN code This is the personal code for your SIM card. You may be asked to enter this code when the instruction: Pin number ? appears after you switch on your phone. Enter the code of between 4 and 8 digits given to you by your operator. These digits will not be displayed on the screen for security reasons. Press # or OK or to validate. PIN2 code (*) If one was given to you by your Operator, a second PIN code provides secure access to certain functions.
2.3 Charging the battery Your phone is powered by a rechargeable battery. A new battery must be charged for at least 4 hours before it is used for the first time. It will reach its nominal capacity after several usage cycles. When your battery has run down, the phone displays it and cuts out. To recharge your battery: Connect the charger to a wall outlet. Connect the end of the charging cable to the bottom of your phone. ;y The phone will start charging.
2.4 Switching on/switching off, starting up To switch on your phone: Control of the PIN code Press to switch on your If your phone phone. displays SIM absent, If access to the SIM card is (long press protected by a secret code, the phone will ask you to enter your press) to switch off your phone and PIN code. check that your SIM Enter the code of between 4 and card is correctly 8 digits given to you when you positioned. were given your SIM card.
Switching off Hold down the key until the end message is displayed. Release the key. The phone switches off. 2.5 Menu access The menu functions permit you to verify or modify the various functions of your phone to adapt it to your needs. Press the scrolling arrows or Direct access to to access the menus. menus Scroll through the menus using the scrolling arrows then press To directly access a OK to access the selected menu.
15 3.1 Making a call International call The network is displayed. Dial the number, including the area code if necessary, by pressing keys on the alphanumeric keypad. Press 0 (long press) to display + then dial the country code without waiting for a tone, then the number you require. Press 3. Initial communication Hands-free mode . During the call, flashes on the screen, and tones may signal the establishment of a connection. When the person you have called answers, speak.
3.2 Receiving a call When you receive a call: Press then speak. The callers number is displayed when it is presented to the network. All incoming and outgoing call numbers are registered in the list of the last calls. 3.3 Volume control Increase or decrease the volume during a conversation by pressing the or keys. 16 3.4 Hands-free mode During a call, you can transfer from handset mode to hands-free mode simply by pressing one key and the reverse. Press .
17 You have the option of personalising the presentation of the menus, and so of limiting access to certain functions (See chapter How to adjust and customize your phone). The following list presents the expert level (limiting itself to the 3rd sub-menu). Services Access to specific services offered by the operator Directory 4. Menu list According to the model of your phone, to the configuration of the networks and associated subscriptions, certain functions may not be available (indicated by *).
Text messages Access to the text mailbox Call services Call forwarding All voice calls All conditional fwd Cancel voice forwards Forward if busy Forward if no answer Forward if unavailable Data forwarding Faxes forwarding View last numbers Options Call Duration and cost of calls (*) Counters Delete durations Costs (*) Delete costs (*) Display of duration Display numbers Anonymous mode Your number Callers number 4.
Controls Customization Menus type Energy saving Screen Saver (*) Greeting message (*) Prog. Key (*) Select language Automatic response Auto.
20 5.1 Directory display You can store the telephone numbers that you call regularly: in the SIM card, in the phone itself. Different icons will inform you of the directory location where the number is stored when you search for it: SIM card directory 5. How to use the directory Your phones directory SIM card pre-set directory 5.2 Storing a number In the Directory menu, select Create record. Validate by pressing OK. Enter the name (the number of accepted characters depends on the SIM card used).
You can enter spaces in the number When sorting by (displayed as commas ,) by location, pressing on pressing (long press) on or #. The the key launches * * for the first figures entered after a space are a search available location; processed in a DTMF sequence pressing on # (usable after a number). returns to the start If necessary, select the call group of the list. to which you want to assign this number.
Activate the Call Groups function If you want the characteristics of the If call groups are not groups to apply to each call: enabled, you cannot attach Go into Directory/Directory correspondents to menu/Call groups. groups. Choose Activate groups. Tick the box and validate. Note: the calls received from contacts who do not belong to a Call group use the parameters provided in the Ringing and beeps menu.
5.5 Sorting The directory menu enables you to sort the stored numbers by name or location; for the latter, the free locations are indicated in the list. 5.6 Sending a short message to a stored number Select the recipient scrolling using the scrolling arrows and validate using OK. Select Send message and validate using OK. Compose your text message. Press OK. Select Send and validate using OK. The recipient number is displayed. Send your message using key. 5.
24 6. How to use the text mailbox and the Easy Message T9 function 6. Text mailbox 6.1 Receiving a short message When you receive a short Access to this message, an icon flashes on your service depends on phone screen, a tone is emitted the network. For and the indicator light flashes red. more information, consult your Your phone indicates: Operator or your the location of the message in the Service Provider.
6.2 Editing a message using Easy Message T9 T9 mode is The Easy Message T9 function activated as soon as helps you to easily enter short you create or modify messages. a message. Select the Text messages/Write new... menu and press OK. Selecting the editing language Language Validate T9 by pressing the By default, the key. Select using the scrolling language used is arrows, the language required that which is and validate by pressing OK.
Additional entry modes The key selects one mode or another. The 123 mode (numeric) inserts numbers. The Insert symbol mode displays a list of symbols and the figures from 1 to 0 that correspond to them. To enter a symbol, simply type the number that appears above the character required, for example: 6 for ?. The symbol is inserted into the text and you return automatically to Easy Message T9 mode. Several lists are accessible using the scrolling arrows.
After validating text, you can choose one of the following options: Send your message Store your message De-activate Zoom Cancel. 6.3 Edited messages 27 The number of messages stored in the SIM card changes depending on the SIM card capacity; contact your Operator or your Service Provider. for further information.
28 7.1 Forwarding calls Forwarding voice calls Depending on your subscription, this service allows you to transfer incoming calls to another number or a mailbox. 7. How to use the call related features 7. Call related features Look out for incompatibilities; for more information, consult your Operator or your Service Provider.
29 Validate by pressing A message on the screen confirms that forwarding has been activated. The forwarding number to the messaging centre depends on the subscription type. You can also cancel all types of forwarding. Warning Cancellations of You can view the status of a type forwarding can of call forwarding in order to verify cause particular reactions in certain whether it is active or not. This networks. function is also useful for controlling the number to which your calls are forwarded.
7.3 Monitoring the duration and cost of calls (*) On the Counters menu you can This data is purely view the duration of the last call indicative and does and all calls made since the last not represent proof. The metering criteria deletion. for the network can The Delete durations menu be appreciably enables you to delete the different (indivisible duration of the last call and reset minutes, etc.). to zero the total calls counter.
On incoming calls, when it is activated, this function displays on your phone the phone number of the person calling (CLIP). This function is only possible if the caller has authorised his identity to be displayed by deactivating his CLIR option. 7.5 Authorising double call (Service depending on the operator) Call waiting During a call, a special tone can You can activate, inform you that another caller is deactivate and view trying to reach you.
32 7.10 Placing calls on hold (Service depending on the operator) During a call, you can put the current call on hold by pressing Ok. During a call, when pressing the @ key, the key changes function and enables you to access different options for the call.
33 2X Place on hold the multi-conference calls except for the current call order number X (private call). 3 Add a call holding (or multi-conference calls) to the current call (or to the multiconference). Tel N° Place on hold the current call (or the multi-conference calls) and call another telephone number. End all calls except for a possible call waiting.
34 8. How to adjust the ringing tones and the vibrator 8. Ringing tones and vibrator 8.1 Selecting the volume and the type of ringing tone You can set your phone to ring on There are numerous receiving calls and/or short tunes available messages. (including a «silent ringing tone») and You can, during adjustment, several volume listen to the melody selected or levels including a not: activate or dont by pressing crescendo. @; the symbol appears barred or not.
8.2 Call groups See chapter How to use the directory for all the functions about call groups. 8.3 Personalising the ringing tone You have the option of creating a personalised call tune. A help menu, accessible by pressing , will guide you. 8.4 Setting the vibrator Wherever you require your calls to arrive discreetly, you can use the vibrator or select the silent mode. Using the scrolling keys, select one of the following options: inactive vibrate, only vibrate, vibrate and ring, vibrate then ring.
Setting the low battery tone If you want your phone to give a warning beep when your battery is low: Tick the box and validate by pressing OK. 8.7 Deleting DTMF tones You can delete the emission of DTMF tones during a call. You can thus make a call, in a comfortable and discreet way for you caller. To be discreet, clear the selecton from the box. Validate by pressing OK. 8.
37 9.1 Customizing your phone Menus type 9. How to adjust and customize your phone You have the option of personalising the presentation of the menus, and so of limiting access to certain functions. Three levels are available: - Expert: presents all of the functions - Essential: presents the main functions - Restricted: limits access to certain functions.
38 Configuring the idle mode (depending on model) You can choose between an animated idle screen or the economy mode. In the Customization/Screen Saver menu, use the scrolling arrows to select the animation you want or the economy mode. Press to access the setting of the animation or economy mode activation interval. Press OK to validate. Note: to exit the economy mode, press . Personalising the welcome screen (depending on model) You can personalise the welcome screen of your phone by typing a text.
Call voice mail Validate Call voice mail. When you press the key you will automatically call your mailbox number. Text messages Validate Text messages. When you press the key you can read the short messages stored in the SIM card or in the phone itself. View calls Validate View calls When you press the key, you can view the list of the last calls made and received if available. 9.
If no network is available, your phone continues to search for one. In all cases, the phone searches for its home network first. In specific cases, manual forcing is possible. Using the scrolling arrows, you can select: Available networks This menu enables you to start a search for all available networks at the present location and to display them. To manually force the chosen network, use the scrolling arrows and validate (press ).
9.7 Converting currencies 41 This menu enables you to convert one currency into another. Using the scrolling arrows, you can select: Rapid exchange If you tick the Rapid exchange box, the converter will operate on the standby screen, enter the digits required and use the scrolling arrows to perform a conversion. Exchange rate Enter the conversion rate corresponding to the two selected currencies. Currencies Enter the symbols of the two currencies to convert.
42 10.How to use the security features of your phone 10.1 Locking the keyboard You can still make This menu enables you to lock your phones keyboard to prevent calls from emergency calls and being made unintentionally in your bag answer calls. or pocket. Tick the Lock box: the keyboard will For a quick keypad locking, press automatically be locked. * then OK from the To unlock your keyboard: standby screen. Press then OK. * After unlocking, the keyboard will be locked after a certain period.
To the question: Verify pin number ?, enter your new PIN code a second time to verify and validate by pressing OK. Checking the PIN number You can activate your PIN number so that it is requested and checked every time the phone is switched on, so that if the phone is lost or stolen, your SIM card cannot be used: To the question: Pin number ?: enter your PIN number and validate (press ). Tick the box Pin number cont and validate by pressing OK. 10.
Once the phone code is activated, you can modify it: To the question: Old phone code?, enter your old phone code and validate (press ). To the question: New phone code? enter your new phone code (a number of between 4 and 8 digits) and validate by pressing OK. To the question: Verify phone code enter your new phone code a second time to verify it and validate by pressing OK. 10.5 Changing the operator password (*) You have an operator password.
You can activate, deactivate, and view the status of the type of call barring. You can also cancel ALL types of barring. 10.8 Setting up the pre-set directory (*) 45 Access to this service depends on your subscription type. For more information contact your Operator or Service Provider. The pre-set directory allows you to This directory is linked to the SIM limit calls. When you activate this card. Thus, its size directory, only the numbers you store in this directory can be called.
46 11. Other functions 11.1 Calculator You can operate the calculator using the following keys: Add @ Subtract Multiply * # Divide OK Equals C Delete : Decimal point Long press on or # or @ or * Monetary operations if there is no calculation in progress Monetary conversion. 11.2 Setting the alarm 11. Other functions To use your phone as an alarm clock: Using the numbers or the scrolling arrows, set the alarm time. Press to go to the next item. Set the minutes. Tick the box and validate by pressing OK.
The ringer is stopped by pressing any key; the alarm remains programmed. The alarm function remains active when the phone is switched off. It is not affected by silent mode. 11.3 Setting the timer 47 The alarm function is represented on the screen by the symbol . Permanent flashing of this symbol indicates that an alarm time has been programmed but the date and time clock has not been initialised.
48 12.WAP Function Mobile Internet The WAP browser remains the exclusive property of Phone.com. It is therefore highly prohibited to modify, translate, reverse engineer, de-compile or disassemble the Phone.com browser or any part thereof. 12. WAP Function From the standby screen, press on the @ key to access the local menu for WAP functions. Depending on model, scrolling menu 0 allows you to access the WAP function. Home: connection to the home page.
- Disconnect which ends the communication (allows a navigation whithout being connected). - Linger timer enables you to set a time limit, after which the phone will disconnect automatically if you have forgotten to disconnect from a service. Reset cache: empties data stored from previous connections. Quit: return to the phone standby screen.
50 13.Games 13. Games Depending on the model, several games are available. The presentation menu guides you on how to best use them.
51 Depending on the model, different accessories are available on your phone: 14.Available accessories Additional batteries Additional chargers Desk charger A cable for data exchange between your phone and a PC Cigarette lighter adapter Hands-free kits Coloured front panels Warning Do not connect/ disconnect the special socket on your phone during a call.
52 Upkeep Clean your phone using a soft slightly damp non fluffy cloth. Battery 15.Upkeep After a long period of non use (several months), when the charger is being connected, the unit might not switch on. In this case: Disconnect the charger, wait a few seconds, and plug it in again. It may be necessary to repeat this several times Maintenance menu This menu contains information that you could be asked for to perform specific operations.
53 The use of your phone is controlled by safety regulations intended to protect both the user and his/her CE marking on the unit conforms to environment. Electrical safety 16.Recommendations directives 1999/5/ EC, 89/336/CEE and 73/23/CEE. Only use the appropriate chargers contained in the manufacturers catalogue. Using another charger could be dangerous and will invalidate the manufacturers warranty. The main plug socket must be easily accessible.
Airplane safety In an airplane, your phone must be switched off to ensure that it does not interfere with the planes systems. Its use is illegal and you could be prosecuted or banned from using cellular networks in the future if you do not abide by these regulations. Areas containing combustibles It is advisable to switch your phone off in the vicinity of gas stations. Regulations limit the use of radio equipment in chemical factories, gas depots and any area where there are mines.
General precautions Do not attempt to open your phone and repair it yourself. The manufacturer cannot be held responsible for any damage/ accident that may result from this. Any work carried out by non-authorised personnel will invalidate your warranty. Do not use your phone in damp areas (bathroom, swimming pool, ). Protect it from water and other liquids. Do not expose your phone to extreme temperatures.
Answers to your questions The telephone does not turn on - Remove the battery and then replace it. or - Connect the telephone to the charger (check that this is plugged in) for approximately 5 minutes. No network recognised - Remove the SIM card. Check that there is no dust or grit in the SIM slot. Replace the SIM card being sure to push it right up to the stop point. Calls to a messaging service or voice server do not get through - Check in the Ringing and beeps/Tones menu that the box is ticked.
